Aims Power 5000 Watt 24 Volt Power Inverter - PWRINV500024W

Aims Power 5000 Watt 24 Volt Power Inverter - PWRINV500024W

This 5000 watt 24 Volt DC  power inverter by AIMS Power converts DC (direct current) power stored by batteries into AC (alternating current) electricity that can be used to run practically any household appliances or tools.

This unit produces a modified sine wave, which is capable of running most  tools, pumps, motors and appliances. Use this product for off-grid back-up power at home, cabin, boat, larger solar systems or anywhere that doesn't have city power.

What really makes this 5000 watt AIMS Power inverter special is its capability to run off at 24 volt DC which allows for more efficiency at higher loads.  This makes the inverter very attractive to users using a 24 volt DC source or multiple batteries.

The biggest incentives for using inverters for electricity include the fact that they make little-to-no noise, making for a more peaceful environment for customers, and that they’re non-polluting, which makes for a great green-energy marketing campaign.

The unit features two easily-accessible AC outlets with a maximum output of 1500 watts. The 200 percent surge capabilities of this unit should only be used as a safety feature. Other safety features include over-temperature and over-load LED indicators that are used as a warning system for the operator.  Also on the AC side of the unit are the battery voltage and amperage meters which display the usage levels of your battery bank. This inverter is equipped with dual cooling fans and over-temperature protection that keeps it from overheating.

Features

• 5000W max continuous power
• Modified sine wave
• Volt meter on front panel to monitor your battery voltage
• Amp meter on front panel to monitor your current use (rate at which battery is drained)
• AC Direct Connect Terminal
• Over Temperature LED indicator
• Over Load LED indicator
• Quadruple ac receptacle that can be used with any separate spliter to provide even more outlets
• On/off switch
• Over Temperature protection
• Over Load protection
• Single cooling fan operation thermally controlled
• Internally fuse protected
• ac output short circuit protection
• Auto reset on most fault conditions
• Aluminum case for optimal cooling
• Pre-wired for remote on/off switch
• Pre-slotted mounting plate
• Instruction manual
• Free 1 year tech support


Specifications

• Continuous output power: 5000 Watts
• Surge power capability (peak power): 10,000 Watts
• dc input / operating voltage: 34 to 20 Volts

• Output voltage: 120 Volts ac +/- 10%
• Output wave form: modified sine wave with phase correction
• Output frequency: 60 Hz +/- 1 Hz
• Battery low voltage alarm: 21.0 +/- 0.5 Volts
• Battery low voltage shutdown: 20.0 +/- 0.5 Volts
• No load current @ 24V: < 0.4 Amps
• Full load efficiency: 90%
• 1/3 load efficiency: 95%
• No load minimum operating temperature: -15 degrees Celsius
• Full load maximum operating temperature: 55 +/- 5 degrees Celsius (automatic shutdown)
• No load draw: Switch on – <1 amp DC. Switch off - <.2 mADC
• AC Output Socket Type: quadruple Type 2 -3 prong
• High input voltage protection: 34.5V
• Low input voltage shutdown: 20.0V
• Internal fuse protection
• Product size (L x W x H): 16.92”X 7.95”X 6.1”
• Unit Weight 16.72 lbs

• Boxed Weight 20 lbs
• UL maximum recommended per outlet 1500W

What our Experts Think

• The AIMS Power PWRINV500024W is a high-capacity 5,000W pure sine wave inverter designed for 24V DC systems, making it ideal for serious off-grid solar, RV, and backup power setups.
• Delivers clean pure sine wave output, ensuring safe operation for sensitive electronics like computers, medical devices, and modern appliances.
• Supports 10,000W surge capacity, allowing reliable startup of motors, pumps, refrigerators, and power tools without failure risk.
• Optimized for 24V battery banks, reducing current draw compared to 12V systems and improving overall efficiency in high-load setups.
• Built for off-grid solar systems, RVs, cabins, mobile workstations, and emergency backup power applications.
• Includes multiple protection systems such as overload, over-temperature, low/high voltage, and short-circuit protection for system safety.
• Equipped with real-time monitoring (voltage/amps) and remote switch capability, improving usability in installed systems.
• Designed with a heavy-duty aluminum housing and active cooling, supporting continuous high-load operation in demanding environments.


Q&A

Q: What is the AIMS Power PWRINV500024W 5000 Watt 24V Power Inverter?
A: The AIMS Power PWRINV500024W is a 5000W industrial-grade inverter that converts 24V DC battery power into 120V AC electricity for off-grid, RV, solar, marine, and backup power systems.

Q: How much power does it provide?
A: It delivers 5000 watts of continuous power with up to 10,000 watts of surge capacity for starting motors, compressors, and heavy appliances.

Q: What type of waveform does it use?
A: This model uses a modified sine wave with phase correction, suitable for most tools, appliances, and general electrical loads.

Q: What systems is it designed for?
A: It is ideal for 24V solar systems, RVs, trucks, boats, cabins, and emergency backup power setups requiring high-capacity AC output.

Q: What safety protections are included?
A: It features overload protection, short-circuit protection, over-temperature shutdown, low/high voltage protection, and internal fuse protection for reliable operation.

Q: What monitoring features does it have?
A: Built-in voltmeter and ammeter display real-time battery voltage and current draw, helping users manage power usage efficiently.

Q: What are its key specifications?
A: It operates at 24V DC input, produces 120V AC output, and typically measures about 17 inches in length with a weight around 17 lbs depending on configuration.

Q: Why choose this inverter?
A: It offers high power output, durable aluminum housing, multiple AC outlets, and strong surge handling, making it a reliable choice for demanding off-grid and mobile power applications.


Maintenance Tips

• Install in a cool, dry, and well-ventilated location; avoid heat, moisture, and direct sunlight to prevent thermal shutdowns.
• Maintain at least proper airflow clearance around the unit so cooling fans and vents stay unobstructed.
• Regularly inspect and tighten 24V battery cables, terminals, and grounding connections to prevent voltage drop and overheating.
• Keep batteries in healthy condition and fully charged, as low voltage can trigger alarms and shutdowns.
• Clean the exterior periodically to prevent dust buildup on vents and heat sinks.
• Ensure correct polarity (positive to positive, negative to negative) during any maintenance or reconnection.
• Avoid running continuously at maximum load (5000W); leave a 20–30% power buffer for long-term reliability.
• Periodically check for overload, over-temperature, or fault indicators and address issues early.
