Bar Cradle Trucks & Pipe Dolly Trucks
Share
When your operation demands reliable transport for bars, pipes, steel rods, and other long heavy stock, a purpose-built cradle truck is the smartest investment you can make. These rugged pipe dolly trucks are engineered from welded steel channel frames and equipped with heavy-duty casters to roll smoothly across warehouse and shop floors. Whether you need a compact ergonomic unit or a full-size structural transporter, there is a bar cradle cart designed to keep your materials secure and your crew productive.
Ergonomic Bed Height Bar Cradle Truck
These heavy-duty bar cradle carts are purpose-built for storing and moving bars, pipes, and other lengthy heavy materials with ease. Each unit sits at an ergonomic bed height of 20 inches, reducing strain during loading and unloading. Swivel casters on every wheel position deliver precision turning and exceptional maneuverability, even in tight spaces.
- 3,000-lb load capacity
- 34-inch overall height
- Cradle dimensions: 21 inches wide Γ 14 inches tall
- Three bed sizes available β all 24 inches wide
- 20-inch ergonomic bed height
- All-welded steel construction
- 6 Γ 2-inch phenolic swivel casters
- Ships fully assembled and shrink-wrapped on a pallet (LTL)
| Model | Bed Size | Price | Weight |
|---|---|---|---|
| LR15 | 24β³ Γ 24β³ | $408 | 75 lbs |
| LR17 | 24β³ Γ 36β³ | $448 | 83 lbs |
| LR19 | 24β³ Γ 48β³ | $478 | 91 lbs |
Low Deck Bar Cradle Truck
Offered in either 5,000 or 10,000-pound capacities, these heavy-duty bar cradle trucks are constructed from robust 3-inch or 4-inch steel channel frames. Their rugged build handles virtually any load you put on them. A six-wheel caster layout β swivel wheels at both ends and rigid casters in the center β provides outstanding maneuverability throughout your facility. Designed specifically for transporting extremely heavy bar stock and pipes, the quality welding and solid construction deliver years of dependable service under harsh conditions.
- Up to 10,000-lb capacity
- All bar and pipe cradle trucks feature 27β³ Γ 14β³ cradles
- 3β³ Γ 3/16β³ thick load supports on every unit
- All units are 30 inches wide, offered in two lengths
- 10K models include four cradles
- Swivel casters on the ends, rigid casters in the center β all phenolic
| Model | Dimensions (W Γ L) | Cradle Size (W Γ H) | Price |
|---|---|---|---|
| LZ2 | 30β³ Γ 96β³ | 27β³ Γ 14β³ | $1,253 |
Structural Bar Cradle Trucks for Extra-Long Pipe & Bar
Built on a structural channel frame, these extra-long pipe and bar transporters come in 10-foot or 12-foot bed lengths. These trucks are large and extremely heavy βΒ they must never be used on ramps, slopes, or any kind of inclined surface.
- 10,000-lb capacity
- Cradles measure 28β³ wide Γ 13β³ high
- All units are 28β³ wide Γ 29β³ tall
- Choose between 120-inch or 144-inch long beds
- 12β³ Γ 3β³ phenolic rigid casters for supreme support
| Model | Dimensions (W Γ L Γ H) | # of Cradles | Price |
|---|---|---|---|
| LZ10 | 28β³ Γ 120β³ Γ 29β³ | 4 | $1,090.00 |
| LZ12 | 28β³ Γ 144β³ Γ 29β³ | 5 | $1,270.00 |
Important Ergonomic & Safety Guidelines for Pipe Dolly Trucks
Pipe dolly trucks and bar cradle carts are outstanding material handling tools for transporting bars, pipes, steel rods, and other long heavy items. However, improper use can create hazards for the operator and those nearby. Review the following guidelines carefully to ensure you select the right cart and use it safely every time.
Operating a Single Bar Cradle Cart
Many jobs only call for one cradle cart to move your stock properly. When using a single unit, always center the load on the cart and make sure the weight is distributed evenly across the full length. Never transport unbalanced materials on a single cart β if weight shifts to one side, the load can tip and fall. Three bed lengths are available (24β³, 36β³, and 48β³), and a good rule of thumb is to never transport materials that are more than three times longer than the cart bed. Confirm the weight of your materials is balanced with no bowing or sagging at the ends, and always stay within published load capacity limits.
Using Two or More Bar Cradle Carts Together
Pairing multiple cradle carts lets you store and move much longer lengths of material. Every additional cart you add increases your total capacity by 3,000 pounds. Multiple pipe dolly trucks are essential when handling unbalanced pipe β for instance, iron duct pipes with a flange on one end. Space the carts evenly beneath the load so the cradles share the weight equally. This prevents sagging and bowing that can damage both your materials and the carts themselves.
LQ Series β 5,000-lb Capacity Bar Cradle Truck
The LQ series features an all-welded steel frame built on a 3-inch structural channel. All pipe dolly trucks in this line come standard with three cradles β one at each end and one in the center. Six-inch phenolic swivel casters at both ends combine with larger 10-inch rigid casters in the middle, allowing the unit to be steered through your workspace with minimal effort.
LZ Series β 10,000-lb Capacity Bar Cradle Truck
The LZ series is a super heavy-duty bar transporter constructed with a 4-inch structural channel frame for superior strength and durability. Each unit arrives with four cradles welded to the frame. Eight-inch swivel casters at the ends and 12-inch center casters deliver effortless rolling even under the heaviest loads.
Low Bed Height Advantage
Two bar cradle truck models feature low bed heights of 14 and 16 inches respectively. This low-profile design makes it much easier to load heavy materials because you don't have to lift them very high off the floor. An added safety benefit: if a load shifts during transit and spills over the side of the bed, the material won't fall from a height greater than 16 inches β significantly reducing the risk of injury from high-impact drops.
