Bar Cradle Trucks & Pipe Dolly Trucks
Share
When it comes to safely moving heavy bars, pipes, steel rods, and other long materials across your facility, bar cradle trucks and pipe dolly trucks are essential equipment. These purpose-built carts are engineered for demanding industrial environments, featuring robust welded steel construction, swivel casters for tight-space maneuverability, and ergonomic designs that reduce worker strain.
Ergonomic Bed Height Bar Cradle Truck
These heavy-duty bar cradle carts are designed for the storage and movement of bar, pipe, and other lengthy heavy materials. Each unit features a comfortable 20-inch ergonomic bed height that reduces bending and lifting strain. All pipe moving carts in this line are equipped with swivel casters, delivering precise turning capability and smooth navigation around corners and through tight spaces.
- 3,000-lb load capacity
- 34" overall height
- All units feature cradles measuring 21" wide x 14" high
- Available in 3 different sizes, each 24" overall width
- 20" ergonomic bed height
- Fully welded steel construction
- 6" x 2" Phenolic casters, all swivel
- Ships fully assembled, shrinkwrapped on a pallet via truck (LTL)
| Model | Bed Size | Price | Weight |
|---|---|---|---|
| LR15 | 24" x 24" | $408 | 75 lbs |
| LR17 | 24" x 36" | $448 | 83 lbs |
| LR19 | 24" x 48" | $478 | 91 lbs |
Low Deck Bar Cradle Truck
Model LZ2 β Low Deck Bar Cradle Truck
10,000-lb Capacity
These heavy-duty bar cradle trucks come with either 5,000 or 10,000 pounds of load capacity. Constructed with strong 3" or 4" steel channel frames, they can manage virtually any material handling challenge. The 6-wheel caster configuration ensures effortless maneuverability within your facility. Commonly used for extremely heavy bar and pipe transport, these rugged pipe dolly trucks are built to endure years of punishing use in harsh industrial conditions.
- 10,000-lb load capacity
- All bar and pipe cradle trucks have cradles 27" wide x 14" high
- 3" wide x 3/16" thick load supports on all units
- All units are 30" wide, available in 2 lengths
- 10K units include 4 cradles
- All units have swivel casters on ends and rigid casters in center; all casters are Phenolic
| Model | Dimensions (W x L) | Cradle Size (W x H) | Price |
|---|---|---|---|
| LZ2 | 30" x 96" | 27" x 14" | $1,253 |
Structural Bar Cradle Trucks for Extra-Long Pipe & Bar
Built with a structural channel frame, these extra-long pipe and bar transporters are available in 10-foot or 12-foot lengths. These trucks are large and extremely sturdy βΒ never use these trucks on ramps, slopes, or any kind of inclined surface.
- 10,000-lb load capacity
- Cradles measure 28" wide x 13" high
- All units are 28" wide x 29" high
- Choose between 120" or 144" long beds
- 12" x 3" Phenolic rigid casters deliver supreme support
| Model | Dimensions (W x L x H) | # of Cradles | Price |
|---|---|---|---|
| LZ10 | 28" x 120" x 29" | 4 | $1,090.00 |
| LZ12 | 28" x 144" x 29" | 5 | $1,270.00 |
Important Safety & Usage Guidelines
Pipe dolly trucks are outstanding material handling carts for transporting bars, pipes, steel rods, and other long heavy objects. However, if used improperly, bar cradle carts can present hazards to the operator and anyone nearby. Please review the following guidelines to ensure safe and proper use and to help you select the right cart for your application.
Using a Single Bar Cradle Cart
In many scenarios, a single bar cradle cart is sufficient to transport your stock materials. When using one cart, always center your load and ensure the bar or pipe is evenly distributed along its entire length. Never move unbalanced materials on a single cradle cart. If the weight is concentrated to one side, the load will be at risk of tipping off. Three different cart lengths are available β 24", 36", and 48" β and a good rule of thumb is to never transport materials more than 3 times longer than the cart itself. This helps ensure proper balance and prevents the ends from bowing or sagging. Always stay within the rated load capacity.
Using Two or More Bar Cradle Carts
Employing multiple bar cradle carts enables the operator to store and transport much longer material lengths. Each additional cradle cart under your load adds 3,000 pounds to your total capacity. Multiple pipe dolly trucks should always be used when handling unbalanced pipe β for instance, iron duct pipes with a flange on one end. For best results, distribute the cradle carts evenly beneath your load to prevent sagging and bowing of materials that could otherwise bend.
LQ Series β 5,000-lb Capacity Bar Cradle Truck
This model is constructed with an all-welded steel frame using 3" structural channel. All pipe dolly trucks in this series include 3 cradles, evenly positioned β one at each end and one in the center. The combination of swivel 6" Phenolic casters on both ends and larger 10" rigid casters in the center allows the unit to be maneuvered with ease throughout your facility.
LZ Series β 10,000-lb Capacity Bar Cradle Truck
The super heavy-duty bar transporter, this series is constructed with 4" structural channel framing. Each unit is fitted with 4 cradles, welded directly to the 4" frame for exceptional strength and lasting durability. This line of bar cradle truck features 8" swivel casters at the ends and 12" center casters for smooth transportation even under the heaviest loads.
Low Bed Height Advantage
The two low-profile bar cradle trucks feature bed heights of 14" and 16" respectively. This low-profile design makes loading heavy materials easier since they don't need to be lifted high off the floor. Additionally, if a load were to spill during transit, materials would not fall from a height greater than 16", significantly reducing the risk of injury from high-impact falls.
