Cooktop Specifications
-
Burners/Zones: 5
-
Cooktop Power: 8,000 BTU (2), 12,000 BTU (2), 17,000 BTU
-
Stainless Steel Griddle: Optional
-
Cast Iron Griddle: Optional
-
Flame Failure Device: Yes
Main Oven Specifications:
-
Multi-Function: Yes
-
Oven Capacity (Cu. Ft.): 4.0
-
Closed Door Broil: Yes
-
Broiler: Yes
-
Broiler Power: 2,200 W
-
Oven Power: 3,300 W
-
Convection: European
-
Convection Element: 2,400 W
-
Convection Fan: 1
-
Glide Rack: Optional
-
Pullout Rack: 2
-
Broiler Pan: Yes
Internal Dimensions (Main Oven):
-
Width: 29 3/4"
-
Depth: 15"
-
Height: 13 3/4"
Overall Dimensions:
-
Width (in.): 35-7/8
-
Height (in.) w/o Backguard: Adjustable from 35-7/16” to 37-¼”
-
Height (in) of Backguard: 2 (8" Optional)
-
Depth: 24"
-
Depth with Backguard: 25-5/8"
-
Oven Height: 23-3/16"
-
Weight (lbs.): 250
Downloads & Manual
What our Expect Think
-
Powerful Dual Fuel Performance – Gas cooktop for precision control, electric oven for even baking.
-
5 High-Efficiency Burners – Includes a dual-ring burner for rapid boiling and precise simmering.
-
True European Convection – Ensures uniform heat distribution for flawless cooking results.
-
Premium Build – 304 stainless steel with color options in Matte Black, White, and Stainless Steel.
-
Large Capacity Oven – 4 cu. ft. space accommodates multiple dishes at once.
-
Luxury Features – Soft-close door, digital clock/timer, and easy-to-clean surfaces.
Q&A
Q: What type of fuel does this range use?
A: This is a dual fuel range, meaning it has a gas cooktop and an electric oven for precise cooking and baking.
Q: How many burners does this range have?
A: It features 5 sealed gas burners, including a high-power burner for rapid heating and a simmer burner for delicate cooking.
Q: What is the oven capacity?
A: The oven has a 4.0 cu. ft. capacity, providing ample space for multi-rack baking and roasting.
Q: Does the oven have convection cooking?
A: Yes, it features a European convection fan for even heat distribution and faster cooking times.
Q: Is this range LP (propane) convertible?
A: Yes, it includes an LP conversion kit for use with propane.
Q: What safety features does this range offer?
A: It includes flame failure safety devices to automatically shut off gas if the flame goes out.
Q: Does this range require professional installation?
A: Yes, professional installation is recommended for proper gas and electrical connections.
Maintenance Tips
-
Clean Burners & Caps: Remove and wash with warm, soapy water to prevent clogging. Ensure they are completely dry before reassembling.
-
Wipe Spills Immediately: Use a damp cloth or mild cleaner to prevent stains and buildup.
-
Use Non-Abrasive Cleaners: Avoid harsh chemicals or scrubbing pads to protect the stainless steel or matte finish.
-
Check for Gas Leaks: Periodically inspect gas connections for safety.
