BECKHOFF Stepping Motor - AS1060-1000

The AS1060-1000 is a robust and reliable stepper motor designed for precise motion control applications within the Servo Products category. This motor is specifically engineered to deliver accurate and consistent performance in a variety of industrial automation tasks, making it an essential component in systems requiring high precision and repeatability. As a part of the stepper motor subcategory, the AS1060-1000 is particularly suitable for use in applications that demand fine incremental control, such as CNC machinery, robotics, and automated assembly lines.

Weighing 3.00 lbs, the AS1060-1000 is compact yet powerful, offering a nominal power rating of 68.8 watts. It operates on a dual voltage system, accepting both 24 VDC and 50 VDC inputs, providing flexibility in its integration into different power configurations. This flexibility makes the motor adaptable to various system requirements, ensuring that it can be easily incorporated into new designs or retrofitted into existing setups without significant modifications.

The motor is a 2-phase stepper, which provides a balance between torque and speed, making it ideal for applications that require both steady holding torque and rapid position changes. The bipolar winding configuration enhances the motor's efficiency, allowing for greater torque output per unit of input current. This design choice ensures that the AS1060-1000 can deliver consistent performance even under demanding operational conditions, where maintaining precise control over movement is critical.

The AS1060-1000 is equipped with 200 steps per revolution, which translates to a step angle of 1.8 degrees. This resolution allows for fine-grained control over movement, enabling the motor to perform smooth and precise positioning tasks. Whether used in applications requiring incremental adjustments or in environments where maintaining a consistent position over long periods is necessary, the 200-step configuration ensures that the motor can meet the demands of high-precision tasks.

With a torque rating of 5 Nm, the AS1060-1000 is capable of delivering substantial force, making it suitable for applications that require the movement of heavy loads or operation against significant resistance. This high torque output, combined with the motor's precision, ensures that it can handle both dynamic and static loads effectively, providing reliable performance in various industrial scenarios.

The motor is designed to operate at a current of 5 A, which is well-matched to its power and torque specifications. This current rating ensures that the motor can maintain its performance characteristics across a wide range of operating conditions, from low-load precision tasks to high-load applications that demand maximum torque. The 5 A current also indicates the motor's efficiency in converting electrical energy into mechanical movement, a critical factor in maintaining overall system efficiency.

In terms of environmental protection, the AS1060-1000 carries an IP20 protection rating. This rating ensures that the motor is adequately protected against solid objects greater than 12.5 mm in size, such as fingers or tools, making it safe for use in controlled industrial environments. While the IP20 rating indicates that the motor is not protected against water ingress, it is suitable for use in dry, indoor environments where exposure to moisture is minimal.

The AS1060-1000 is equipped with M12 connectors, which are standard in industrial automation for their reliability and ease of use. These connectors provide secure electrical connections, ensuring that the motor receives consistent power and control signals even in environments subject to vibration or movement. The use of M12 connectors also simplifies the motor's integration into existing systems, as they are widely used and compatible with a range of industrial components.

The motor's shaft is designed with a fitted keyway, which enhances the motor's ability to transmit torque to attached components without slippage. This design is particularly useful in applications where precise alignment and secure attachment of the load are critical. The keyway ensures that the motor's torque is effectively transferred to the driven component, maintaining the accuracy and reliability of the system as a whole.

Dimensionally, the AS1060-1000 features a flange size of 86 mm and a shaft diameter of 14 mm. These dimensions make the motor compatible with a wide range of mounting and coupling options, allowing for flexible integration into different mechanical systems. The 86 mm flange provides a stable mounting surface, ensuring that the motor can be securely attached to the equipment it drives, while the 14 mm shaft is a standard size that fits many common couplings and pulleys used in industrial applications.

In summary, the AS1060-1000 stepper motor is a high-performance component designed for precise and reliable motion control in industrial environments. Its combination of dual voltage operation, high torque output, and fine step resolution makes it suitable for a wide range of applications, from light-duty tasks requiring precision to heavy-duty operations demanding significant force. The motor's robust construction, including its IP20 protection rating and M12 connectors, ensures that it can withstand the rigors of industrial use while providing consistent and accurate performance. Whether used in new installations or as part of an upgrade to existing systems, the AS1060-1000 offers a reliable and flexible solution for motion control challenges in modern automation systems.
