The square post can be positioned anywhere along with the rack.  All posts are manufactured from square tube steel with a minimum yield strength of 345Mpa, ensuring safety for the vertical storage of slab bundles.

Features

• The maximum number of marble or granite slabs that can be safely stored per bay at a 4° lean depends on the slab thickness and dimensions.
• Aardwolf has developed a simple calculator for users to calculate the slab storage capacity.
• The slab rack rail is combined with sixteen steel tube posts, which have a height of 1798mm and a steel post base of 1600-1800mm for storage.
• This rack is the best storage solution, offering cost-saving and economic effects for users.


What our Experts Think

• Heavy-Duty Storage:
  Designed to store large slabs of marble and granite, supporting up to 9,400 lbs (4,700 lbs per post) when fully assembled with 20 posts.

• Durable Construction:
  Made from galvanized steel rails and square tube steel posts with a yield strength of 345 MPa, ensuring long-lasting durability and strength.

• Adjustable Configuration:
  The posts can be placed anywhere along the rails in 2.2" (57 mm) increments, allowing customization for various slab sizes and thicknesses.

• Protective Design:
  Features timber battens on the rails to prevent scratches and chips, and square rubber caps on the posts for additional surface protection.

• Flexible Height Options:
  Posts are available in heights ranging from 47.2" to 70.9" (1,200 mm to 1,800 mm), providing flexibility for different storage needs.

Q&A

Q: What is the Aardwolf ASR0110 Slab Rack Kit?
A: The ASR0110 is a galvanized steel storage system designed for safely storing marble, granite, and other stone slabs vertically, preventing damage and maximizing space efficiency.

Q: What components are included in the ASR0110 kit?
A: The kit comprises two 3-meter galvanized steel rails, each with timber battens to protect slabs, and sixteen 2" x 2" x 70.8" square steel posts with 5 mm wall thickness and rubber caps.

Q: What are the dimensions of the rails and posts?
A: Each rail measures 2979 mm x 164 mm x 165 mm, and each post stands 1798 mm tall with a base width of 1600–1800 mm.

Q: How is the rack assembled?
A: The posts fit into square holes along the rails, spaced 57 mm apart, allowing for adjustable placement to accommodate slabs of varying thicknesses.

Q: What is the weight of the ASR0110 kit?
A: The total weight of the kit is approximately 172 lbs (78 kg).

Q: Where can I purchase the ASR0110 Slab Rack Kit?
A: The ASR0110 is available for purchase through various distributors and online retailers. Please check with local suppliers or online marketplaces for availability.

Maintenance Tips

Regular Cleaning:

• After each use, clean the rack to remove dust, debris, and any material residues.

• Use a soft brush or cloth to clean the surfaces.

• Wipe all parts dry to prevent moisture buildup.

Structural Inspections:

• Periodically inspect the rack for signs of wear or damage.

• Check for rust, bent components, or any structural issues.

• Address any issues promptly to maintain safety and functionality.

Lubrication:

• Lubricate moving parts, such as the post bases, to ensure smooth operation.

• Use a suitable lubricant that does not attract excessive dust or debris.
