SH Series “Super Hub™” Low-Pressure Spring Driven Hose Reels
COXREELS® SH Series “Super Hub™” spring driven hose reels, like the P Series, have a long history of dependable performance. The larger chassis and frame accommodate longer lengths and larger diameters of hose. Coxreels’ original Super Hub™ dual axle support system increases the stability during operation, reduces vibration and strengthens the structural integrity of the reel.
- Professional grade heavy duty steel construction
- Rolled edges & ribbed discs provide strength & safety
- Leading 2-year manufacturer's limited warranty
- Made in the U.S.A. - Sold & Supported Worldwide
Features
- SWIVEL - Machined from solid brass 90° full-flow NPT swivel for simple seal maintenance and fast and easy hose installation. No need to remove the reel from its mount.
- CARTRIDGE MOTOR - Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance.
- CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
- 1/4" STEEL BASE - Sturdy single pedestal design with solid one piece steel base and support post, no weld, for maximum stability. Exclusive Super Hub™dual axle support system.
- MULTI-POSITION GUIDE ARM - Versatile guide arm adjusts to wall, floor, ceiling, and vehicle mounting positions.
- OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish,adjustable solid rubber hose stop, and sturdy permanently lubricated precision bearings.
Specifications
| MODEL |
I.D |
O.D |
LENGTH |
HOSE |
MAX PSI |
SHIP WEIGHT (LBS) |
OVERALL DIMENSIONS (W) (H) (L) |
MOUNTING PATTERN (M) (N) |
BASE (X) (Y) |
| SH-N-160 |
1/4" |
1/2" |
60' |
Yes |
300 |
50 |
7.63"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-3100 |
3/8" |
5/8" |
100' |
Yes |
300 |
71 |
8.25"(W) 21.25"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-350 |
3/8" |
5/8" |
50' |
Yes |
300 |
50 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-360 |
3/8" |
5/8" |
60' |
Yes |
300 |
53 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-375 |
3/8" |
5/8" |
75' |
Yes |
300 |
68 |
8.25"(W) 21.25"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-4100 |
1/2" |
3/4" |
100' |
Yes |
300 |
81 |
8.75"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-435 |
1/2" |
3/4" |
35' |
Yes |
300 |
49 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-440 |
1/2" |
3/4" |
40' |
Yes |
300 |
52 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-450 |
1/2" |
3/4" |
50' |
Yes |
300 |
54 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-475 |
1/2" |
3/4" |
75' |
Yes |
300 |
68 |
8.75"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-525 |
3/4" |
1 1/16" |
25' |
Yes |
300 |
52 |
9.38"(W) 25.5"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-535 |
3/4" |
1 1/16" |
35' |
Yes |
300 |
57 |
9.38"(W) 25.5"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SH-N-550 |
3/4" |
1 1/16" |
50' |
Yes |
300 |
69 |
9.88"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-160 |
1/4" |
1/2" |
60' |
No |
300 |
50 |
7.63"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-3100 |
3/8" |
5/8" |
100' |
No |
300 |
60 |
8.25"(W) 21.25"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-350 |
3/8" |
5/8" |
50' |
No |
300 |
44 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-360 |
3/8" |
5/8" |
60' |
No |
300 |
46 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-375 |
3/8" |
5/8" |
75' |
No |
300 |
59 |
8.25"(W) 21.25"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-4100 |
1/2" |
3/4" |
100' |
No |
300 |
66 |
8.75"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-435 |
1/2" |
3/4" |
35' |
No |
300 |
43 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-440 |
1/2" |
3/4" |
40' |
No |
300 |
45 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-450 |
1/2" |
3/4" |
50' |
No |
300 |
46 |
8.25"(W) 21.25"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-475 |
1/2" |
3/4" |
75' |
No |
300 |
57 |
8.75"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-525 |
3/4" |
1 1/16" |
25' |
No |
300 |
57 |
9.38"(W) 25.5"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-535 |
3/4" |
1 1/16" |
35' |
No |
300 |
47 |
9.38"(W) 25.5"(H) 19.5"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| SHL-N-550 |
3/4" |
1 1/16" |
50' |
No |
300 |
56 |
9.88"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
What Our Experts Think
-
Super Hub™ Technology: Features an advanced hub design for smooth hose retraction and enhanced durability, perfect for high-use environments.
-
Low-Pressure Capability: Ideal for air, water, and light fluid transfer, supporting various industries such as automotive, agriculture, and manufacturing.
-
Spring-Driven Retraction: Provides effortless automatic rewind, reducing manual effort and improving operational efficiency.
-
Heavy-Duty Construction: Built to last in demanding conditions, ensuring long-term performance and reliability.
-
Corrosion-Resistant Finish: Resists rust and wear, making it suitable for both indoor and outdoor applications.
-
Compact Design: Space-efficient, keeping hoses organized and reducing clutter in the workspace.
Q&A
Q: What is the Coxreels SH Series “Super Hub™” Low Pressure Spring Driven Hose Reel - SH-N-160?
A: A low-pressure, spring-driven hose reel featuring the Super Hub™ system for smooth, efficient hose management and retraction.
Q: What is the hose capacity?
A: This reel holds up to 160 feet of low-pressure hose, making it perfect for various light industrial and mobile applications.
Q: What is the Super Hub™ technology?
A: The Super Hub™ system reduces friction during hose operation, providing smoother retraction and extending the reel's lifespan.
Q: How does the spring-driven mechanism work?
A: The reel uses a spring-driven system that automatically retracts the hose, making hose management quick and hassle-free.
Q: What materials is the reel made from?
A: Constructed with durable, corrosion-resistant materials to ensure longevity and reliable performance in demanding environments.
Q: Where can this reel be used?
A: Ideal for agricultural, automotive, and light industrial applications that require efficient low-pressure hose management.
Maintenance Tips
-
Model: SH-N-160
-
Hose Capacity: Holds up to 150 feet of 1/2” low-pressure hose
-
Pressure Rating: Rated for low-pressure applications up to 300 PSI
-
Construction: Heavy-duty steel frame with corrosion-resistant powder-coated finish for long-lasting durability
-
Drive Mechanism: Spring-driven automatic rewind for smooth and effortless hose retraction
-
Swivel Inlet: Full-flow brass swivel ensures efficient and unrestricted fluid transfer
-
Roller Design: Multi-position guide arm with reinforced rollers for smooth and consistent hose payout
-
Mounting Type: Wall, floor, or ceiling mount for versatile installation options
-
Applications: Ideal for low-pressure fluid transfer in industrial, automotive, and maintenance environments
-
Temperature Range: Operates effectively across a wide temperature range
-
Weight: Varies based on hose configuration
