DK2 22,000LB JP Hydraulic Winch

by DK2
SKU 10TJP
Save 6% Save 6%
Original price $4,106.26
Original price $4,106.26 - Original price $4,106.26
Original price $4,106.26
Current price $3,859.99
$3,859.99 - $3,859.99
Current price $3,859.99
  • CLEARANCE SALE.

  • ITEMS LEFT.

  • PEOPLE are also watching that product.


DK2 22,000LB JP HYRDAULIC WINCH


THE JP SERIES WINCHES HAVE BEEN DEVELOPED FOR THE PROFESSIONAL OPERATOR.

BUILT SPECIFICALLY FOR MILITARY USE & ABLE TO WITHSTAND EXTREME CLIMATES AND TEMPERATURES.

These winches have been designed to ensure that as a part of an installation solution they can meet the requirements of EN 14492 : 1. Superb heavy duty winches supplied complete with balance valve, cable and heavy duty tensioner. Standard features include air operated clutch, high precision 2 stage planetary gearing and a rugged high torque motor. The ultimate winch for heavy recovery and commercial applications.

  • Rugged high torque motor

  • 2 stage planetary gearing

  • Complete with balance valve

  • Air operated freespool

  • Rugged and compact for long life

  • Heavy duty steel cast frame

  • Rope and tensioner as standard

ITEM NUMBER 10TJP
RATED LINE PULL 22000 LBS (10000 KG)
GEARING 39:1
BRAKING ACTION AUTO HYDRAULIC
DRUM SIZE - DIAMETER x LENGTH 138 x 316mm (5.42 x 12.44')
CABLE - DIAMETER x LENGTH 15mm x 48m (0.59' x 157')
DIMENSIONS 830 x 390 x 320mm (32.6 x 15.3 x 12.6')
MOUNTING PATTERN 431 x 64 / 192mm (16.9 x 2.5 / 7.5')
WEIGHT 165 KG (363 LBS)
CERTIFICATION CE CERTIFIED
LAYER OF ROPE / CABLE LINE PULL: LBS (KGS)
1 22046 (10000)
2 16889 (7661)
3 14615 (6630)
4 12881 (5843)
LINE PULL: LBS (KGS) LINE SPEED FT/MIN (M/MIN) FLOW L/MIN • PRESSURE MPA
0 5.9 (1.8) 15 • 25
4000 (1814) 11.7 (3.6) 30 • 42
8000 (3629) 19.6 (6.0) 50 • 85
15000 (6804) 23.6 (7.2) 60 • 140
22046 (10000) 29.7 (9.0) 75 • 175








Manual Instruction

Technical Diagram

Brochure
