DK2 30,000LB JP Hydraulic Winch

DK2 30,000LB JP Hydraulic Winch

by DK2
SKU 13.5TJP
Save 6% Save 6%
$7,115.00
$7,115.00 - $7,115.00
$7,115.00
$6,688.99
$6,688.99 - $6,688.99
$6,688.99

  • CLEARANCE SALE.

  • ITEMS LEFT.

  • PEOPLE are also watching that product.


DK2 30,000LB JP HYDRAULIC WINCH

THE JP SERIES WINCHES HAVE BEEN DEVELOPED FOR THE PROFESSIONAL OPERATOR.

BUILT SPECIFICALLY FOR MILITARY USE & ABLE TO WITHSTAND EXTREME CLIMATES AND TEMPERATURES.

These winches have been designed to ensure that as a part of an installation solution they can meet the requirements of EN 14492 : 1. Superb heavy duty winches supplied complete with balance valve, cable and heavy duty tensioner. Standard features include air operated clutch, high precision 2 stage planetary gearing and a rugged high torque motor. The ultimate winch for heavy recovery and commercial applications.

  • Full float heavy duty planetary gearing

  • Multi disc friction brake

  • High torque industrial motor

  • Air and manual clutch operation

  • Heavy duty rope tensioner as standard

  • Minimum 10:1 rope/drum ratio

  • Balance valve as standard

ITEM NUMBER 13.5TJP
RATED LINE PULL 29762 LBS (13500 KG)
GEARING 36:1
BRAKING ACTION AUTO HYDRAULIC
DRUM SIZE - DIAMETER x LENGTH 190 x 340mm (7.48 x 13.39')
CABLE - DIAMETER x LENGTH 18mm x 50m (0.71' x 164')
DIMENSIONS 1050 x 640 x 405mm (41.34 x 25.2 x 15.9')
MOUNTING PATTERN 522mm x 180 / 280mm (20.5' x 7 / 11')
WEIGHT 271 KG (597 LBS)
CERTIFICATION CE CERTIFIED
MAX FLOW L/MIN 60 L/MIN
MAX PRESSURE MPA 170 BAR

Manual Instruction

Technical Diagram

Brochure

Order shipment preparation takes 3 days. Once shipped orders usually takes 2 weeks to be delivered. These are estimations; can be delayed for reasons beyond our control. You can always contact us to know the exact time once you placed an order with us. Have a look at our
