EDWARDS Quick Change Punch Assembly - ED9-AC1001

• Accepts both Standard and Oversize Punch & Die Sets.
• Compatible with all Edwards Ironworkers.
• Increase your efficiency by saving time and money with the Quick Change Punch Assembly.
• Quick Change Punch Assembly.
• The perfect Accessory to quickly change between multiple size punch and die sets.

What our Experts Think

• Fast Tool Change Capability — the EDWARDS Quick Change Punch Assembly (ED9‑AC1001) lets you swap different punch & die sizes in seconds, drastically reducing downtime compared with conventional punch holders.
• Supports Both Standard & Oversize Sets — accepts standard and oversize punches and dies, giving you versatile hole‑making options without extra adapters.
• Compatible with All Edwards Ironworkers — installs easily across a wide range of Edwards models, so your upgrade works on 40 T through 120 T machines (and older models too).
• Boosts Shop Efficiency — ideal for shops running multiple hole sizes, this assembly cuts setup time and keeps operators productive on batch work.
• Rugged, Precision‑Machined Design — hardened, shop‑ready construction gives reliable performance and long service life under heavy use.
• Compact & Lightweight — at about ~12 lb, it’s easy to handle yet robust enough for industrial punching.

Q&A

Q1: What is the ED9‑AC1001 Quick Change Punch Assembly?
A: A quick‑change punch assembly that lets you swap punch & die sets rapidly on your Edwards ironworker — saving setup time when working with multiple hole sizes.

Q2: What punching tooling does it accept?
A: Designed to accept both standard and oversize punch & die sets, giving you flexibility for a wide range of hole diameters.

Q3: Which machines is it compatible with?
A: Works with all Edwards Ironworkers, from smaller 40 Ton units up through heavy‑duty 120 Ton machines (both older and newer models).

Q4: How does it improve productivity?
A: It dramatically reduces punch changeover time, improving workflow efficiency when performing varied punching tasks in fabrication jobs.

Q5: Why is quick change capability valuable?
A: Swapping between different hole sizes without lengthy setups cuts downtime, boosts throughput, and keeps operators productive on repeat jobs.

Q6: How heavy and portable is it?
A: The unit weighs approximately 12 lbs and is compact (~11″ × 7″ × 5″), making it easy to install or remove.

Q7: Is installation difficult?
A: No — it installs into the punch station like a standard punch assembly, requiring no special tools beyond typical ironworker setup.

Q8: What is the main benefit for shops?
A: Offers fast punch & die changes which is especially useful in multi‑size production runs and reduces time wasted on swapping tooling.

Q9: Is it built for heavy use?
A: Yes — engineered for prolonged use in metal fabrication, structural steel work, and industrial punching applications.

Q10: What’s the primary advantage of this accessory?
A: It provides a versatile and efficient punching workflow, letting you adapt punch sizes quickly without interrupting production.

Maintenance Tips

• Clean After Every Use: Wipe punch holder, guides, and contact surfaces to remove metal chips and debris — prevents buildup that can affect fit and operation.
• Lubricate Moving Parts: Apply light machine oil to quick‑change fittings and mating surfaces to reduce friction and ensure smooth punch/die swaps.
• Inspect for Wear & Damage: Regularly check the assembly for cracks, burrs, or worn locating features; replace damaged components to maintain precise punch alignment.
• Verify Fit & Alignment: After installing in your ironworker, confirm the quick‑change assembly seats squarely and securely with each punch/die set.
• Tighten Fasteners: Periodically verify actuators, set screws, or retaining hardware are tight to avoid movement under load.
• Protect from Corrosion: Store in a clean, dry area and apply a rust inhibitor on exposed steel when idle.
