Honda Horizontal Engine - HDA,GX200-TX2
Honda GX200 TX2 Horizontal OHV Engine, 196cc , 5.8 Net HP, 5/8" x 2-7/16" Threaded Shaft, Model GX200UT2TX2
Specifications
| Brand |
Honda |
| Model Number |
GX200UT2TX2 |
| Internal ID |
HDA-GX200-TX2 |
| Warranty |
3 Year Residential |
| Available to California |
Not Available to Ship to California |
| Weight |
41.0 lb |
| PTO Height |
4-11/64" |
| Power Output |
5.8 HP @ 3600 RPM |
| Torque |
9.1 lb-ft (12.4 Nm) @ 2500 rpm |
| Crankshaft Orientation |
Horizontal |
| Crankshaft Type |
Threaded |
| Crankshaft Diameter |
5/8" |
| Crankshaft Length |
2-7/16" |
| Crankshaft Dimensions |
5/8" x 2-7/16" |
| Crankshaft Rotation Direction |
Counter-Clockwise |
| Starter Type |
Recoil |
| Ignition System |
Transistorized Magneto |
| Carburetor |
Butterfly |
| Number of Cylinders |
One |
| Cylinder Bore |
Cast Iron Sleeve |
| Air Cleaner |
Dual Element |
| Oil Capacity |
0.63 qt |
| Low Oil Alert |
Yes |
| Fuel Type |
Unleaded 86 Octane or Higher |
| Fuel Tank Capacity |
3.3 qt |
| Fuel Pump |
N/A |
| Governor System |
Mechanical |
| Lubrication System |
Splash |
| Controls |
Manual Choke, Manual/Remote (Wire) Throttle |
| Bore x Stroke |
68mm x 54mm |
| Compression Ratio |
8.5 : 1 |
| Charging System |
N/A |
| Muffler |
Standard |
What Our Experts Think
-
Reliable Power: The Honda GX200-TX2 Horizontal Engine delivers strong, consistent power, making it ideal for a variety of medium-duty equipment.
-
Durable Design: Built to withstand tough conditions, this engine offers outstanding durability for long-term use in demanding environments.
-
Fuel Efficiency: Designed to optimize fuel consumption, it provides longer operation time and fewer refuels, helping to reduce operating costs.
-
Smooth & Quiet Performance: Its advanced engineering ensures smooth operation with minimal vibration and reduced noise, enhancing user comfort.
-
Low Maintenance: The GX200-TX2 is easy to maintain, featuring simple access to key components, reducing downtime and simplifying upkeep.
-
Versatile Applications: Ideal for a range of applications, from pressure washers and generators to small industrial machinery, providing reliable power for diverse tasks.
Q&A
Q: What is the Honda Horizontal Engine - HDA, GX200-TX2?
A: The Honda Horizontal Engine - HDA, GX200-TX2 is a versatile, high-performance engine designed for a variety of outdoor equipment. It provides reliable power for medium-duty applications such as generators, pumps, and pressure washers.
Q: What are the key features of the GX200-TX2 engine?
A: The GX200-TX2 engine features an OHV (Overhead Valve) design for improved fuel efficiency, lower emissions, and smooth operation. It also offers easy starting, high torque, and exceptional durability, making it suitable for demanding tasks.
Q: What are the benefits of using the GX200-TX2 engine?
A: The GX200-TX2 engine offers reliable, consistent power, excellent fuel economy, and minimal maintenance. Its robust design ensures long-lasting performance in commercial and industrial applications.
Q: Is the GX200-TX2 engine easy to maintain?
A: Yes, this engine is designed for easy maintenance with easily accessible components for routine upkeep, such as oil changes and air filter replacements, ensuring minimal downtime.
Q: Can the GX200-TX2 engine be used for various outdoor equipment?
A: Yes, the GX200-TX2 is highly versatile and perfect for a wide range of medium-duty outdoor equipment, including pressure washers, water pumps, generators, and lawnmowers.
Maintenance Tips
-
Oil Change: Change the engine oil every 50 hours or annually, whichever comes first.
-
Air Filter: Clean or replace the air filter as needed to ensure proper airflow and engine efficiency.
-
Spark Plug: Inspect and replace the spark plug annually or if performance issues arise.
-
Fuel System: Use fresh, clean fuel and drain the tank when the engine is stored for long periods.
-
Coolant: Check and maintain proper coolant levels to prevent overheating.
-
General Inspection: Clean around the engine, remove debris, and inspect for any leaks.
