Honda Horizontal Engine - HDA,GX200-HX2
Honda GX200 HX2 Horizontal OHV Engine with 6:1 Gear Reduction, 196cc, 5.8 Net HP, 3/4" x 1-31/32" Crankshaft, No Clutch, Oil Alert, Includes Fuel Tank, Model GX200UTHX2
Specifications
| Brand |
Honda |
| Model Number |
GX200UT2HX2 |
| Internal ID |
HDA-GX200-HX2 |
| Replaces Models |
GX200-HX2, GX200U-HX2, GX200UT-HX2, GX200UT2-HX2 |
| Warranty |
3 Year Residential |
| Available to California |
Not Available to Ship to California |
| Weight |
47.0 lb |
| PTO Height |
4-11/64" |
| Power Output |
5.8 HP @ 3600 RPM |
| Torque |
9.1 lb-ft (12.4 Nm) @ 2500 rpm |
| Crankshaft Orientation |
Horizontal |
| Crankshaft Type |
Reduction Type |
| Crankshaft Diameter |
3/4" |
| Crankshaft Length |
1-31/32" |
| Crankshaft Dimensions |
3/4" x 1-31/32" |
| Keyway |
3/16" |
| Crankshaft Rotation Direction |
Counter-Clockwise |
| Starter Type |
Recoil |
| Ignition System |
Transistorized Magneto |
| Carburetor |
Butterfly |
| Number of Cylinders |
One |
| Cylinder Bore |
Cast Iron Sleeve |
| Air Cleaner |
Dual Element |
| Oil Capacity |
0.63 qt |
| Fuel Type |
Unleaded 86 Octane or Higher |
| Fuel Tank Capacity |
3.3 qt |
| Fuel Pump |
N/A |
| Governor System |
Mechanical |
| Lubrication System |
Splash |
| Controls |
Manual Choke |
| Bore x Stroke |
68mm x 54mm |
| Compression Ratio |
8.5 : 1 |
| Charging System |
N/A |
What Our Experts Think
-
Strong Performance: The Honda GX200-HX2 Horizontal Engine offers reliable and consistent power, making it suitable for a wide range of medium-duty machinery.
-
Durability: Built to endure tough conditions, it provides long-lasting performance, ensuring minimal downtime and maximum reliability.
-
Fuel Efficiency: Optimized for fuel efficiency, this engine helps reduce operating costs by delivering more run time per tank of fuel.
-
Smooth & Quiet Operation: With its advanced engineering, the GX200-HX2 operates smoothly with reduced vibrations, contributing to a quieter and more comfortable user experience.
-
Low Maintenance: Designed for easy maintenance, it ensures quick access to essential parts, making upkeep simple and reducing service time.
-
Versatile Applications: Ideal for a variety of equipment, from generators to pumps and pressure washers, this engine provides consistent, powerful performance across multiple tasks.
Q&A
Q: What is the Honda Horizontal Engine - HDA, GX200-HX2?
A: The Honda Horizontal Engine - HDA, GX200-HX2 is a durable, high-performance engine designed for medium-duty outdoor equipment. It offers reliable power and efficiency for applications like generators, water pumps, and pressure washers.
Q: What are the key features of the GX200-HX2 engine?
A: The GX200-HX2 features an OHV (Overhead Valve) design, which provides improved fuel efficiency, smoother operation, and lower emissions. It also offers easy starting, high torque, and long-lasting performance for demanding applications.
Q: What are the benefits of using the GX200-HX2 engine?
A: The GX200-HX2 engine delivers reliable power, excellent fuel economy, and minimal maintenance. Its rugged construction ensures extended durability, making it ideal for both commercial and industrial applications.
Q: Is the GX200-HX2 engine easy to maintain?
A: Yes, the GX200-HX2 is designed for ease of maintenance, with easily accessible components for routine tasks such as oil changes, air filter replacements, and general servicing, keeping downtime to a minimum.
Q: Can the GX200-HX2 engine be used for different outdoor equipment?
A: Absolutely! The GX200-HX2 engine is versatile and works well in various medium-duty outdoor machinery, including generators, pumps, pressure washers, and lawnmowers, providing dependable performance for demanding jobs.
Maintenance Tips
-
Oil Change: Change the engine oil every 50 hours or annually, whichever comes first.
-
Air Filter: Clean or replace the air filter as needed to ensure proper engine efficiency.
-
Spark Plug: Inspect and replace the spark plug annually or when performance issues arise.
-
Fuel System: Use fresh, clean fuel and drain the tank when storing the engine for extended periods.
-
Coolant: Ensure proper coolant levels to prevent overheating.
-
General Inspection: Regularly inspect the engine for leaks, clean out debris, and maintain proper airflow.
