Honda Horizontal Engine with Electric Start - HDA,GX240-QAE2
Honda GX240 QAE2 Horizontal OHV Engine with Electric Start and 3-Amp Charging System, 270cc, 7.9 Net HP, 1" x 3-31/64" Crankshaft, Model GX240UT2QAE2
Specifications
| Brand |
Honda |
| Model Number |
GX240UT2QAE2 |
| Internal ID |
HDA-GX240-QAE2 |
| Warranty |
3 Year Residential |
| Available to California |
Not Available to Ship to California |
| Weight |
71.0 lb |
| PTO Height |
5-1/4" |
| Power Output |
7.9 HP @ 3600 RPM |
| Torque |
13.4 lb-ft (18.3 Nm) @ 2,500 RPM |
| Crankshaft Orientation |
Horizontal |
| Crankshaft Type |
Straight |
| Crankshaft Diameter |
1" |
| Crankshaft Length |
3-31/64" |
| Crankshaft Dimensions |
1" x 3-31/64" |
| Crankshaft End Tapped Size |
7/16"-20 |
| Keyway |
1/4" |
| Crankshaft Rotation Direction |
Counter-Clockwise |
| Starter Type |
Electric & Recoil |
| Ignition System |
Digital CDI with Variable Ignition Timing |
| Carburetor |
Butterfly Float |
| Number of Cylinders |
One |
| Cylinder Bore |
Cast Iron Sleeve |
| Air Cleaner |
Dual Element |
| Oil Capacity |
1.16 qt |
| Low Oil Alert |
Yes |
| Fuel Type |
Unleaded 86 Octane or Higher |
| Fuel Tank Capacity |
5.6 qt |
| Fuel Pump |
N/A |
| Governor System |
Centrifugal Mass |
| Lubrication System |
Splash |
| Controls |
Manual Choke, Manual/Remote (Rod) Throttle |
| Bore x Stroke |
77mm x 58mm |
| Compression Ratio |
8.5 : 1 |
| Charging System |
3 Amp |
| Muffler |
Standard, Exhaust Pipe Protector, Spark Arrester, Deflector |
What Our Experts Think
-
Reliable Power: The Honda GX240-QAE2 Horizontal Engine provides consistent and strong power, making it perfect for medium-duty applications and heavy-duty equipment.
-
Electric Start Convenience: With its electric start feature, it eliminates the need for manual pulls, providing quick and effortless startup every time.
-
Fuel Efficient: Designed for fuel optimization, the GX240-QAE2 offers extended run times, reducing the frequency of refueling and lowering operational costs.
-
Smooth & Quiet Operation: The engine operates with minimal vibration and noise, ensuring a smooth, quiet performance that enhances user comfort.
-
Durability: Built with Honda’s renowned durability, this engine is designed to withstand tough conditions and offer long-lasting performance in demanding environments.
-
Versatile Applications: Ideal for a range of machinery, from generators and pumps to pressure washers and other industrial equipment, providing reliable power for a variety of tasks.
Q&A
Q: What is the Honda Horizontal Engine with Electric Start - HDA, GX240-QAE2?
A: The Honda Horizontal Engine - HDA, GX240-QAE2 is a reliable and powerful engine designed for outdoor equipment. Featuring an electric start system, it provides easy operation and is ideal for use in generators, water pumps, pressure washers, and other heavy-duty machinery.
Q: What are the key features of the GX240-QAE2 engine?
A: The GX240-QAE2 engine is equipped with Honda’s OHV (Overhead Valve) technology, which provides better fuel efficiency, lower emissions, and smoother operation. Its electric start system ensures quick and easy ignition, while its durable build offers reliable performance in demanding conditions.
Q: What are the benefits of using the GX240-QAE2 engine?
A: The GX240-QAE2 engine offers excellent fuel efficiency, low emissions, and minimal maintenance. Its electric start system provides convenience, and its high torque makes it perfect for heavy-duty applications, delivering reliable and consistent power for commercial and residential equipment.
Q: Is the GX240-QAE2 engine easy to maintain?
A: Yes, the GX240-QAE2 is designed for low-maintenance operation, with accessible components that make tasks like oil changes and air filter replacements quick and simple, helping to reduce downtime and keep the engine running smoothly.
Q: Can the GX240-QAE2 engine be used for different outdoor equipment?
A: Absolutely! The GX240-QAE2 engine is versatile and suitable for various outdoor applications, including generators, water pumps, pressure washers, and other heavy-duty machinery that require reliable and efficient power.
Maintenance Tips
-
Oil Change: Change the engine oil every 100 hours or annually, whichever comes first.
-
Air Filter: Clean or replace the air filter regularly to ensure proper airflow and engine efficiency.
-
Spark Plug: Inspect and replace the spark plug annually or if you notice performance issues.
-
Fuel System: Use fresh, clean fuel and drain the tank if the engine is not used for long periods.
-
Battery Maintenance: Keep the battery clean, charged, and inspect for corrosion to ensure reliable electric start functionality.
-
Coolant: Ensure proper coolant levels to prevent overheating and maintain optimal performance.
-
General Inspection: Regularly inspect for leaks, clean around the engine, and ensure components are secure.
