Laguna Tools Classic Planer PX|22 - MPLANPX2275-0130

The all-new PX|22 planers are an innovative new design for Laguna planers. The Laguna PX|22 planers are loaded with features to make woodworking safer and more enjoyable. The PX|22 is available in 2 configurations: 7.5 HP single phase or 10 HP three phase.

The ShearTec: II features 4-sided solid carbide inserts with a T-shoulder rather than a cone-shaped design, which helps prevent cracking of the inserts.

The ShearTec II cuttherhead comes as standard equipment on PX|20 ShearTec II Jointer. The ShearTec II is a 6-row carbide insert cutterhead that produces a superior surface finish on all woods including challenging hardwoods. The ShearTec II knives and fasteners have a T-step design to maximize clamping force on the knives preventing knife cracking and chatter. The 4-sided carbide insert knives produce a shear cut for flawless results. The ShearTec II cutterhead has deep grooves that make the cutterhead very quiet and improve shaving ejection. The 4-sided knives can be rotated for a new cutting edge without need for a knife setting jig.

Features

Motor – The PX|22 comes with either 7.5 HP Single Phase or 10 HP 3 Phase motor
Segmented Infeed Roller – Allows for multiple boards to be fed without having individual boards stall out due to small variations in thickness
Electronic Variable Speed – Allows users to speed up the material feed for quick thicknessing or to use slower rates for more cuts per inch. This feature is something that is normally found on much more expensive models
Infeed and Outfeed Rollers – The PX|22 features infeed and outfeed rollers to assist with material loading and feeding and provide a compact footprint
Digital Readout – The DRO makes setting precise thickness easier
Ergonomic Control Panel – Machine controls and DRO have been moved to the control panel at the top of the machine and angled toward the machine operator for easy access and better visibility
Improved Dust Collection – The 5? diameter dust chute offers the option to point to right or left to optimize dust collection system layout.
4-Post Bed Support – Provides precise and consistent performance with every cut
ShearTec II Cutterhead – The ShearTec II is standard on the PX|20 Planer. The ShearTec II is a 6-row carbide insert cutterhead that produces a superior surface finish on all woods including challenging hardwoods. The ShearTec II knives and fasteners have a T-step design to maximize clamping force on the knives preventing knife cracking and chatter. The 4-sided carbide insert knives produce a shear cut for flawless results. The ShearTec II cutterhead has deep grooves that make the cutterhead very quiet and improve shaving ejection. The 4-sided knives can be rotated for a new cutting edge without the need for a knife setting jig

Specifications

Motor: 220v 7.5HP 1 Phase 60hz/23 Amp./220v 10HP 3 Phase 60hz/28 Amp.
CSA: Yes
Bed Size: 22″ x 28″
Pull-Out Extension: 6″
Max. Depth Of Cut: ¼″
Max. Stock Thickness: 8″
Min. Stock Thickness: ½″
Min. Stock Length: 9″
Max. Stock Width: 22″
Feed Speed: 10 – 30 FPM Variable Speed
Dust Port Diameter: 5″ Left Or Right
Cutterhead RPM: 5000
Cutterhead Diameter: 3-½″
Cutterhead Insert #: 150 x 4-Sided Carbide, 6 Row
Plug (NEMA 5-15P): No
Thickness Readout: Wixey DRO
Noise (1m away): 83dB
Dimensions Set Up Approx. 40″ x 46″
Dimensions Shipping: 44″ x 38″ x 48-½″
Net/Ship Weight: 867/955 Lbs.

Video

Manual

PX|22 Planer Manual

What Our Experts Think

Heavy-Duty Precision: The PX|22 delivers professional-grade surfacing with a solid cast-iron construction for vibration-free, accurate planing.
Powerful Performance: Equipped with a 7.5 HP motor, it easily handles wide hardwood boards and continuous production workloads.
Helical Cutterhead Advantage: The segmented carbide inserts provide ultra-smooth finishes, reduced noise, and longer blade life.
User-Friendly Design: Digital thickness readout and adjustable bed rollers simplify setup and ensure consistent results.
Industrial Build Quality: Robust frame, large infeed/outfeed tables, and superior dust collection make it ideal for commercial shops.

Q&A

Q: What is the maximum cutting width of the PX|22?
A: It planes up to 22 inches wide, ideal for large panels and furniture components.

Q: Does it use a helical cutterhead?
A: Yes, it features a 4-row helical cutterhead with carbide inserts for cleaner cuts and quieter operation.

Q: What motor power does it include?
A: Powered by a 7.5 HP motor for consistent performance on heavy stock.

Q: Is the thickness display digital?
A: Yes, a digital thickness gauge ensures accurate, repeatable adjustments.

Maintenance Tips

Keep Rollers & Table Clean: Remove resin and dust buildup to prevent snipe and uneven feeding.
Rotate Cutter Inserts: Turn inserts 90° when dull to maintain a sharp edge and smooth finish.
Lubricate Moving Parts: Apply lubricant to elevation screws and chain drives monthly.
Inspect Belts & Drive Components: Check for tension, wear, and alignment regularly.
Clean Dust System: Ensure the dust hood and ports remain clear to preserve airflow and machine longevity.
