Marshall CV610-U3W-V2 Compact PTZ Camera with USB 3.0/2.0 and HDMI - CV610U3WV2

Marshall CV610-U3W-V2 Compact PTZ Camera with USB 3.0/2.0 and HDMI - CV610U3WV2

Marshall's new second-generation CV610-U3W-V2 is a compact USB PTZ camera with backwards compatibility (USB 3.0/2.0), a wider horizontal Angle-of-View (AOV) at 63°, and simultaneous HDMI livestream output. The CV610-U3W-V2 has a compact footprint and uses common control protocols over USB (UVC 1.5 and UAV 2.0) making it a versatile and easy-to-use PTZ camera that can be integrated with a variety of different software codecs. The CV610-U3W-V2 was developed to deliver next-level performance for any UCC, teleconference, Pro A/V, or livestreaming applications with HD video output in 1920x1080p at 60/50/30/25 fps, and 1280x720 at 60/50/30/25 fps.

Features

• 1/2.8" 2MP CMOS Sensor

• 10x Optical/12x Digital Zoom

• Up to 1920 x 1080p60 Video Output

• 128 Preset Positions

• 2-Megapixel HD Sensor

• 10x Optical Zoom: 62.5°~6.4°Horizontal AOV (12x Digital Zoom)

• Compact overall footprint (approx.): 145mm diameter, 112mm head diameter, 155mm height

• USB 3.0/2.0 (uncompressed) output with simultaneous HDMI output

• Full-HD resolutions: 1920x1080p, 1280x720p

• Frame rates: 60, 50, 30, 25 fps

• HDMI output resolution can be set independently of USB output resolutions

• Onboard audio mic & 3.5mm TRS audio jack (optional input)

• Pan-Tilt Range: 350° Horizontal Pan Range / 120° Tilt Range

• Up to 128 presets with quiet, smooth transitions

• Control via common software UVC codecs, IR Remote, RS232, RS485, and USB 3.0/2.0

• Breakout Cable, USB 3.0/2.0 cable, and 12V Power Cord included with camera

What Our Experts Think

• Full HD 1080p Video – Delivers crisp, high-quality footage at up to 60fps.
• 10x Optical Zoom – Ensures sharp, detailed close-ups with smooth zoom control.
• USB 3.0/2.0 & HDMI Outputs – Provides flexible connectivity for streaming, conferencing, and broadcasting.
• Smooth & Silent PTZ Movement – Enables precise pan, tilt, and zoom adjustments for dynamic shots.
• Plug-and-Play Compatibility – Works seamlessly with Zoom, Teams, Skype, and other video conferencing platforms.
• Low-Light Optimization – Features advanced noise reduction for clear images in dim environments.
• Compact & Elegant White Design – Perfect for corporate meetings, classrooms, houses of worship, and live streaming setups.

Q&A

Q: What is the Marshall CV610-U3W-V2 Compact PTZ Camera?
A: The Marshall CV610-U3W-V2 is a compact PTZ camera with USB 3.0, USB 2.0, and HDMI outputs, designed for video conferencing, live streaming, and professional AV applications.

Q: What is this camera used for?
A: It is ideal for corporate meetings, classrooms, houses of worship, telemedicine, and live streaming, providing high-quality video with smooth pan, tilt, and zoom control.

Q: What resolution does this camera support?
A: The CV610-U3W-V2 captures Full HD 1080p video at 60fps, ensuring sharp, detailed, and fluid visuals.

Q: What are the connectivity options?
A: It features USB 3.0 and 2.0 for plug-and-play use, HDMI for direct video output, and RS-232 for remote control integration.

Q: Can this camera be controlled remotely?
A: Yes, it supports RS-232 serial control and UVC control over USB, allowing seamless operation with PTZ controllers and software-based video platforms.

Q: What are the key benefits of this camera?
A: It offers high-quality Full HD video, flexible connectivity (USB 3.0/2.0, HDMI), smooth PTZ movements, and easy plug-and-play functionality, making it an excellent choice for professional video applications.

Maintenance Tips

• Keep the Lens Clean – Use a microfiber cloth and lens-safe cleaner to remove dust and smudges.
• Check Cable Connections – Ensure USB, HDMI, and power cables are securely connected to avoid signal interruptions.
• Update Firmware Regularly – Install the latest firmware updates for optimal performance and compatibility.
• Test PTZ Movement – Periodically pan, tilt, and zoom the camera to ensure smooth operation.
• Avoid Overheating – Keep the camera well-ventilated and away from direct heat sources.
• Use a Surge Protector – Prevent power-related damage with a regulated power source.
• Store in a Safe Environment – Keep the camera protected from dust, moisture, and extreme temperatures.
• Secure the Mounting Setup – Ensure proper installation and periodically check for stability.
