Marshall Electronics Input Module for AR-DM2-L Audio Monitor - ARDMAESBNC

Marshall Electronics  Input Module for AR-DM2-L Audio Monitor - ARDMAESBNC

What our Experts Think

• Professional Dual HD‑SDI Inputs – Adds two HD‑SDI input channels to compatible MD‑series rack monitors for versatile source connectivity. Supports standard high‑definition feeds used in broadcast and pro video workflows.

• Loop‑Through Output – Includes a loop‑through output so you can daisy‑chain the SDI signal to another display or recorder without signal loss.

• Modular & Swappable – Designed to fit the ’B’‑type expansion slot on Marshall MD series monitors, making upgrades simple and adaptable to changing production needs.

• Compatible with MD434 & VMD503 – Works seamlessly with popular modular rack monitors to expand input options in studios, OB vans, and AV setups.

• Durable & Reliable – Built for continuous, professional use with trusted Marshall Electronics quality and backed by a manufacturer warranty.

• Expert‑Recommended – Ideal for multi‑camera environments and professional video monitoring where flexible SDI input options are essential.

Q&A

Q: What is this module for?
A: An input expansion module that adds digital audio capability to the Marshall AR‑DM2‑L Digital Audio Monitor mainframe.

Q: What type of audio inputs does it provide?
A: It offers 4 unbalanced AES/EBU digital audio inputs on BNC connectors for professional multi‑channel digital sources.

Q: Are outputs included?
A: Yes — 4 passive loop‑through outputs let you pass signals to other equipment without conversion.

Q: How many channels can it support?
A: Supports up to 4‑channel stereo or Dolby multi‑channel decoding when paired with the monitor.

Q: Which device does it work with?
A: Designed specifically for the AR‑DM2‑L 16‑Channel Digital Audio Monitor by Marshall Electronics.

Maintenance Tips

• Keep BNC & Audio Connectors Clean – Use compressed air or a soft brush to prevent dust buildup.

• Avoid Cable Strain – Handle audio and BNC cables gently; avoid sharp bends or tension.

• Ensure Secure Installation – Confirm the module is firmly seated in the AR-DM2-L monitor slot.

• Use Quality Cables – Certified audio and BNC cables maintain optimal signal quality.

• Power Off Before Handling – Prevent electrical damage when installing or removing the module.

• Inspect Regularly – Check connectors and module for wear or loose connections.

• Protect from Dust & Moisture – Store in a dry, clean environment when not in use.

• Test Signal Integrity – Periodically verify proper audio and video signal transfer.
