Hoshizaki PT1A-HS-HS | 28" Wide 2 Door Top Mount Pass-Thru Refrigerator - PT1A-HS-HS

Hoshizaki PT1A-HS-HS | 28" Wide 2 Door Top Mount Pass-Thru Refrigerator - PT1A-HS-HS

The PT1A-HS-HS Steelheart Series Pass Thru single section refrigerator with a half stainless doors is a space saving workhorse. Solid state digital controller with temperature alarms and LED display (°F or °C). With a interior capacity of 24.2 cubic feet this efficient pass thru refrigerator and front air flow design is perfect for hot/tight kitchens. The PT1A-HS-HS is constructed of stainless steel, which protects this unit from accidental damage and rust. Plus, it is easy to clean.
The PT1A-HS-HS also includes Interior LED light bar is mounted horizontally on the ceiling, (4) 4″ stem casters (2 with brakes) are standard, plus a field reversible, spring assisted self closing doors with stay open feature (no kit req’d). Electrical consumption of 1.31 kWh/day at 5 Amps, 10 ft long cord with a 5 – 15P NEMA plug. Optional kits: 6″ Legs, Epoxy or stainless steel shelves, Tray/pan slides, Foot pedal door opener, Additional air filter. The unit is ETL Safety (US & C) Listed, ETL Sanitation, ENERGY STAR Qualified and includes a six years parts , five years labor , and seven years compressor .

Features

• Dimensions: 27.5″ W x 35.75″ D x 79.5″ H
• Interior capacity of 24.2 cubic feet
• Unique “ducted” air distribution system
• Epoxy electrocoated (E-Coat) evaporator coil to help fight corrosion for extended life
• Stainless steel exterior (front, sides, top) and a stainless steel interior
• Field reversible, spring assisted self closing doors with stay open feature (no kit req’d)
• One piece, full door length, extruded aluminum flush mount door handle
• Lockable Half Stainless Doors
• Insulated with 2 3/8″ CFC free, foamed in place polyurethane
• Interior LED light bar is mounted horizontally on the ceiling
• Solid state digital controller with temperature alarms and LED display (°F or °C)
• R290 refrigerant
• (4) 4″ Stem Casters (2 with brakes) are standard
• Includes 3 epoxy coated wire coated wire shelves adjustable in 1″ increments on stainless steel supports
• Optional kits: 6″ Legs, Epoxy or stainless steel shelves, Tray/pan slides, Foot pedal door opener, Additional air filter
• Nominal Compres. of 770 BTU/hr at 1/4 HP
• 115v/60/1, 10 ft. cord and plug
• Shipping Crate: 38.25″ L x 31.5″ D x 81″ H at 357 lbs
• ENERGY STAR Qualified


Specifications

What our Experts Think

• Pass-Thru Convenience – Dual-door access makes it easy to load and retrieve items from both sides.

• Top-Mounted Compressor – Maximizes interior space and keeps the cooling system away from floor debris.

• Heavy-Duty Stainless Steel – Built for durability and easy maintenance in high-traffic environments.

• Precise Temperature Control – Ensures consistent cooling to keep food fresh.

• Adjustable Shelving – Provides versatile storage options for various food and beverage items.

Q&A

Q: What is the Hoshizaki PT1A-HS-HS?
A: The Hoshizaki PT1A-HS-HS is a 28" wide, top-mount pass-thru refrigerator with two solid half doors, ideal for commercial kitchens and food service operations.

Q: What makes a pass-thru refrigerator useful?
A: A pass-thru design allows access from both sides, making it perfect for kitchen efficiency and front-of-house service.

Q: Does it have adjustable shelving?
A: Yes, it comes with adjustable shelves to customize storage for different food items.

Q: Is it energy-efficient?
A: Yes, it features LED lighting, high-quality insulation, and an efficient cooling system for energy savings.

Maintenance Tips

• Clean Doors & Gaskets: Wipe daily to ensure a tight seal and prevent air leaks.

• Monitor Temperature: Keep between 34-40°F for optimal food preservation.

• Inspect & Clean Coils: Every 3 months, remove dust for efficient cooling.

• Check & Clear Drain Lines: Prevent water buildup and potential leaks.

• Avoid Overloading: Ensure proper airflow for consistent refrigeration.
