AMGO 409-HP 9,000 lbs Parking Lift - 409-HP

AMGO 409-HP 9,000 lbs Parking Lift - 409-HP

The AMGO 409-HP Pro Series is designed to accommodate a wide range of vehicles, including cars, SUVs, and light trucks. With an impressive lifting capacity of 9,000 lbs, it is well-suited for demanding tasks like parking longer and taller vehicles. This lift is easy to install, requires minimal maintenance, and provides exceptional mobility, making it a reliable and efficient solution for various lifting needs. Let me know if you'd like further refinements!

Features

• 9,000lbs lifting capacity
• High lifting rise: 82
• AMGO exclusive hidden safety locks and manual single-point lock release
• Multi safety locks in each column
• Adjustable lock ladder
• Automatic safety locks combined with redundant anti-fall devices
• Double-S shaped columns for increased strength
• Non-slip platform
• Standard configuration with 4 wheel stops which is more safe
• Flexible Design: power side column can be installed at any corner
• Designed portable,it can be moved easily by using the optional caster kits
• 220V or 110V single phase power unit
• Meets or exceeds the standards prescribed by European Standard EN-1493

What our Experts Think

• A high-capacity parking lift designed for serious garage optimization. The AMGO 409-HP delivers a 9,000 lb lifting capacity, making it suitable for cars, SUVs, and light trucks while enabling true double-parking efficiency in a compact footprint.
• Built for taller and longer vehicles. Its extended platform and increased lifting height allow it to accommodate higher-roof SUVs and extended wheelbase vehicles more comfortably than standard 4-post parking lifts.
• Space-efficient commercial-grade design. Engineered to fit roughly within a standard parking bay, it helps maximize vertical storage without requiring structural modifications to most garages or workshops.
• Strong emphasis on safety and control. Features include concealed mechanical safety locks, a manual single-point release system, and multiple locking positions for secure vehicle storage at height.
• Smooth, stable lifting performance. Dual hydraulic cylinders and synchronized cable system ensure balanced elevation, reducing platform flex and improving long-term reliability under regular use.
• Practical for both storage and light service. While primarily a parking lift, it can support maintenance tasks when paired with compatible accessories like rolling jacks, expanding its workshop usefulness.
• Flexible installation options. The power unit can be mounted in different positions, and optional caster kits allow repositioning when needed, improving layout adaptability in tight spaces.

Q&A

Q: What is the AMGO 409-HP 4-Post Parking Lift?
A: The AMGO 409-HP is a 9,000 lb capacity four-post parking lift designed for vehicle storage and light service use, allowing efficient double-parking of cars, SUVs, and light trucks in residential or commercial garages.

Q: What vehicles can the 409-HP lift?
A: It supports most passenger cars, SUVs, vans, and light-duty trucks up to 9,000 lbs, making it suitable for both home garage storage and shop environments.

Q: How high does the AMGO 409-HP lift?
A: The lift provides a maximum lifting height of approximately 88 inches (about 7.3 ft), offering enough clearance for stacking vehicles or performing light undercarriage work.

Q: Does the 409-HP require anchoring?
A: No. It is designed as a portable parking lift that can be installed without special foundations and optionally moved using caster kits.

Q: What safety features does the AMGO 409-HP include?
A: It includes a concealed safety lock system with single-point manual release, dual safety locking mechanisms, and cable-slack protection for secure operation.

Q: Why choose the AMGO 409-HP?
A: It combines high lifting height, strong structural columns, foldable ramps, and flexible installation options, making it a space-efficient solution for parking and storage in tight garages or shops.

Maintenance Tips

• Lubricate cables monthly to reduce friction and ensure smooth, even lifting performance.
• Inspect all cables, pulleys, pins, and fasteners regularly for wear, corrosion, or loosening.
• Re-torque anchor bolts monthly (approx. 150 N·m) to maintain structural stability.
• Check hydraulic hoses, fittings, and power unit for leaks, pressure loss, or damage.
• Lubricate rollers and safety lock mechanisms with 90WT gear oil or equivalent.
• Inspect and test safety lock engagement before regular operation.
• Check equalizer cable tension every 6 months and adjust for level lifting across runways.
• Verify columns remain plumb and properly aligned during routine inspections.
• Inspect runway surfaces and structural welds for wear or deformation.
• Keep hydraulic cylinder rods clean and free from dirt, rust, and scratches.
• Replace hydraulic oil after first 3 months of use, then annually (use N46 anti-wear hydraulic oil).
• Operate at least one full lift cycle daily to help remove trapped air from the hydraulic system.
• Clean dust seals, pulleys, and cable guides regularly to extend service life.
• Follow manufacturer maintenance schedule strictly to ensure long-term safety and reliability.
