Baumalight MX230 Flail Mower For Mini Excavators - BML-MX230-F2000-EWC1.5-6-B

Baumalight MX230 Flail Mower For Mini Excavators - BML-MX230-F2000-EWC1.5-6-B

by Baumalight
SKU BML-MX230-F2000-EWC1.5-6-B
Save up to 6% Save 6%
$5,500.00
$5,500.00 - $8,000.00
$5,500.00
$5,170.99
$5,170.99 - $7,520.99
$5,170.99

  • CLEARANCE SALE.

  • ITEMS LEFT.

  • PEOPLE are also watching that product.

Baumalight MX230 Flail Mower For Mini Excavators - BML-MX230-F2000-EWC1.5-6-B

The Baumalight MX230 is the most economical flail mulcher for mini excavators, ideal for efficiently cutting heavy grass and small brush with its 22 flail teeth. The teeth pivot to minimize damage upon stone contact. This mulcher offers optional F3000 blade teeth, enhancing its cutting capacity with a robust 6mm thickness and smooth spiral pattern for seamless mulching.

The Baumalight MX230 Flail Mulcher for Mini Excavators is a robust, economical solution for clearing brush and heavy vegetation with your mini excavator. Equipped with 22 dynamic flail teeth, the MX230 efficiently handles heavy grass and small-diameter brush, with a unique flail design that minimizes damage by swinging back when encountering stones. This feature extends the life of each tooth, ensuring longer operational periods without the need for replacements.

Upgradable to F3000 blade teeth, the MX230 enhances its mulching capability, with thicker 6mm blades arranged in a spiral pattern for smoother, more efficient mulching. This light-duty excavator-mounted forestry mulcher is designed for precision, allowing easy maneuverability around objects, whether in ditches or overhead scenarios. The integrated relief valve safeguards the hydraulic motor and system from pressure spikes, enhancing durability and maintenance ease.
Model No. MX230 MX330 MX530 MX530R MX548R MX948R MX960R MX1160R
A02 A02 A02 A02 A03 A03 A03 A03
Path Width 38" 38" 40" 40" 62" 70" 90" 90"
Rotor Width 30" 30" 30" 30" 48" 48" 60" 60"
Minimum Tracked Excavator Ton 2 3 4 4 7 12 18 18
Minimum Wheeled Excavator Ton 4 5 6 6 9 15 21 21
Max Tracked Excavator Ton 6 8 12 12 20 30 33 33
Max wheeled Excavator Ton 8 10 14 14 22 33 36 36
Cutting Depth Level Level 1.5" Above to 1" Below Grade 1.5" Above to 1" Below Grade 1.5" Above to 1" Below Grade Level Level Level
Holder Style Swing Fixed Fixed Fixed Fixed Fixed Fixed Fixed
Cutting Style Flail High Speed Teeth Carbide Tipped Bolt In Carbide Tipped Bolt In Carbide Tipped Bolt In Double Tipped Carbide Double Tipped Carbide Sharpenable Planer teeth
Tooth Part number F2000 H3000 P5000 P5000 P5000 R9000 R9000 P11000
Number of cutters 22 36 44 44 72 27 38 31
Rotor Shaft Size 1.5" 2" 2" 2" 2" 2" 2" 2"
Rotor Diameter (tool tips) 17.25" 15" 15" 15" 15" 18.5" 18.5" 18.5"
Rotor Weight (with tools) 125 lbs 175 lbs 300 lbs 300 lbs 408 lbs 617 lbs 860 lbs 872 lbs
No. of Motor 1 1 1 1 1 1 1 1
Case Drain Not important Not important See motor options See motor options Critical Critical Critical Critical
Unit Weight 500 lbs 750 lbs 1036 lbs 1166 lbs 2167 lbs 2838 lbs 2910 lbs 2925 lbs



Maximum Brush Cutting Sizes
(Brush Diameter in Inches)
200 Series

MOTOR PSI CASE DRAIN 10 GPM 12 GPM 15 GPM 18 GPM 20 GPM
RPM 832 1060 1250 1390
F2000 Series Motor Standard Cup Teeth 2500
3000
3500		 Not Important for Roller-Vane motors 0.225"
0.338"
0.338"		 0.25"
0.375"
0.375"		 0.375"
0.5"
0.5"		 0.5"
0.75"
0.75"		 0.75"
1"
1"
RPM 832 1060 1250 1390
F3000 Series Motor Heavy Blade Teeth 2500
3000
3500		 Not Important for Roller-Vane motors 0.45"
0.675"
0.675"		 0.5"
0.75"
0.75"		 0.75"
1"
1"		 1"
1.5"
1.5"		 1.5"
2"
2"



 

Order shipment preparation takes 3 days. Once shipped orders usually take 2 weeks to be delivered. These are estimations; delivery can be delayed for reasons beyond our control. You can always contact us to know the exact delivery time once you placed an order with us. Have a look at our shipping policy here.
