Coxreels EZ-PC Series Apring Driven "Power Cord" Reels - EZ-PC13-5012-A
EZ-PC Series Apring Driven "Power Cord" Reels
COXREELS EZ-PC Series spring driven "Power Cord" reels are heavy duty, industrial grade power sources. They replace tangled extension cords and self-retract to increase safety, productivity and efficiency. Modelled after the P and SH Series, the PC Series are designed for long-lasting, trouble-free performance even under the most demanding conditions.
- Professional grade heavy duty steel construction.
- Rolled edges & ribbed discs provide strength & safety.
- Leading 2-year manufacturer's limited warranty.
- Made in the U.S.A. - Sold & Supported Worldwide.
Features
- COMPONENT COVER - External, easily accesible, heavy gauge CPC™ powder coated steel components cover for fast and simple slip ring routine maintenance. No need to remove the reel from its mount.
- EZ-COIL EQUIPPED - Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance. Coxreels patented safety system that retracts up to 80% slower than conventional reels.
- CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
- MULTI-POSITION GUIDE ARM - Versatile guide arm adjusts to wall, floor, ceiling, and vehicle mounting positions.
- OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish, adjustable solid rubber cord stop, 5' lead cable and grounding plug, sturdy permanently lubricated precision bearings.
Specifications
| MODEL |
LENGTH |
HOSE |
SHIP WEIGHT (LBS) |
AMPS |
VOLTS |
OVERALL DIMENSIONS (W) (H) (L) |
MOUNTING PATTERN (M) (N) |
BASE (X) (Y) |
| EZ-PC13-5012-A |
50' |
Yes |
40 |
20 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5012-B |
50' |
Yes |
41 |
20 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5012-F |
50' |
Yes |
42 |
20 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5012-X |
50' |
Yes |
40 |
20 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-A |
50' |
Yes |
34 |
13 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-C |
50' |
Yes |
37 |
0.3 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-D |
50' |
Yes |
37 |
13 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-E |
50' |
Yes |
36 |
13 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-H |
50' |
Yes |
37 |
0.3 |
115 |
8.50"(W) 14.88"(H) 13.50"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-K |
50' |
Yes |
37 |
0.3 |
115 |
8.50"(W) 14.88"(H) 13.50"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13-5016-M |
50' |
Yes |
37 |
0.3 |
115 |
8.50"(W) 14.88"(H) 13.50"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13L-5012 |
50' |
No |
29 |
25 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC13L-5016 |
50' |
No |
31 |
25 |
115 |
8.5"(W) 14.88"(H) 13.5"(L) |
3"(M) 5"(N) |
5"(X) 6"(Y) |
| EZ-PC24-0012-A |
100' |
Yes |
90 |
20 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0012-B |
100' |
Yes |
92 |
20 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0012-F |
100' |
Yes |
90 |
20 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0012-X |
100' |
Yes |
81 |
20 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0016-A |
100' |
Yes |
80 |
13 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0016-C |
100' |
Yes |
82 |
13 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0016-D |
100' |
Yes |
80 |
13 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24-0016-E |
100' |
Yes |
80 |
13 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24L-0012 |
100' |
No |
64 |
25 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| EZ-PC24L-0016 |
100' |
No |
62 |
25 |
115 |
10.25"(W) 25.5"(H) 24"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
What Our Experts Think
-
Power Cord Management: Designed specifically to handle heavy-duty power cords, preventing tangles and extending the lifespan of cords.
-
Spring-Driven Retraction: Automatic retraction for quick and easy storage, keeping cords neatly organized and easily accessible.
-
Durable Construction: Built to withstand demanding industrial environments, offering long-lasting performance even under tough conditions.
-
Corrosion-Resistant Coating: Protects the reel from rust and wear, ensuring durability in harsh weather or work conditions.
-
Space-Saving Design: Optimized to store cords efficiently without taking up unnecessary space in your workspace.
-
Versatile Applications: Perfect for construction, manufacturing, and any industry requiring reliable power cord management.
-
Easy Installation & Maintenance: Designed for hassle-free installation and low maintenance for long-term use.
Q&A
Q: What is the Coxreels EZ-PC Series Spring Driven "Power Cord" Reel - EZ-PC13-5012-A?
A: The Coxreels EZ-PC13-5012-A is a spring-driven power cord reel designed to manage and store electrical cords in an organized manner, ensuring efficient and safe use in various work environments.
Q: What is the power cord capacity of this reel?
A: The EZ-PC13-5012-A can hold up to 50 feet of power cord, making it ideal for areas where electrical cords need to be extended and retracted frequently.
Q: How does the spring-driven mechanism work?
A: The reel features an automatic spring rewind system, which smoothly retracts the power cord after use, keeping your workspace tidy and minimizing the risk of tangling.
Q: Is the reel durable?
A: Yes, the EZ-PC Series is made from heavy-duty steel and has a corrosion-resistant finish, ensuring durability and long-lasting performance in demanding environments.
Q: Is this reel easy to install?
A: Yes, the EZ-PC13-5012-A offers flexible mounting options, including wall, floor, or ceiling installation, allowing for convenient placement based on your workspace needs.
Q: What are typical applications for this reel?
A: This reel is ideal for industrial, commercial, and workshop environments where power cords need to be stored safely and efficiently, such as in construction sites, factories, and maintenance areas.
Maintenance Tips
-
Regular Cleaning: Wipe down the reel and power cord with a damp cloth to remove dust, dirt, and debris. Avoid using harsh chemicals that may damage the reel’s surface.
-
Lubricate Moving Parts: Apply a silicone-based lubricant to the spring mechanism and other moving components for smooth operation and longevity.
-
Inspect Power Cord and Fittings: Regularly check the power cord for wear, fraying, or cracks, and ensure that all fittings are secure. Replace any damaged cord sections immediately to avoid electrical hazards.
-
Monitor Voltage and Current: Ensure that the electrical system operates within the recommended voltage and current limits to prevent damage to the reel or cord.
-
Adjust Spring Tension: If the cord retraction becomes slow or uneven, adjust the spring tension according to the manufacturer’s instructions to maintain smooth operation.
-
Check for Overheating: Ensure the reel is not exposed to extreme heat that could affect the cord or internal components.
-
Tighten Fasteners: Periodically inspect and tighten all bolts, screws, and mounting hardware to ensure the reel is securely mounted and properly aligned.
-
Proper Storage: Store the reel in a dry, cool location to prevent exposure to moisture, corrosion, and environmental factors that could damage the power cord or reel.
