Coxreels SS Series "Stainless Steel" Low Pressure Spring Driven Hose Reels - P-LPL-335-SS
SS Series "Stainless Steel" Low Pressure Spring Driven Hose Reels
COXREELS SS Series "Stainless Steel" spring driven hose reels have similar features to their related series, but are constructed of high quality electro-polished stainless steel with stainless steel fluid paths. They offer clean, non-corrosive performance in applications that require it, such as food and chemical processing, marinas, and anywhere that rust, corrosion and contamination thrive.
- Professional grade heavy duty steel construction
- Rolled edges & ribbed discs provide strength & safety
- Leading 2-year manufacturer's limited warranty
- Made in the U.S.A. - Sold & Supported Worldwide
Features
-
SWIVELĀ - Non-corrosive external fluid path with machined from high quality stainless steel 90Ė full-flow NPT swivel inlet.
-
CARTRIDGE MOTORĀ - Electro-polished stainless steel lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance.
-
CNC SPUN DISCSĀ - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
-
1/4" STEEL BASEĀ - Sturdy single pedestal design with solid one piece stainless steel base and support post, no weld, for maximum stability and professional grade strength without the weight.
-
MULTI-POSITION GUIDE ARMĀ - Versatile stainless steel guide arm adjusts to wall, floor, ceiling, and vehicle mounting positions.
-
OTHER FEATURES INCLUDEĀ - Sturdy permanently lubricated precision bearings.
SpecificationsĀ
| MODEL |
I.D |
O.D |
LENGTH |
HOSE |
MAX PSI |
SHIP WEIGHT (LBS) |
OVERALL DIMENSIONS (W) (H) (L) |
MOUNTING PATTERN (M) (N) |
BASE (X) (Y) |
| P-LPL-335-SS |
3/8" |
1/2" |
35' |
No |
300 |
34 |
6.75"(W) 18.63"(H) 17.13"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| P-LPL-350-SS |
3/8" |
5/8" |
50' |
No |
300 |
39 |
6.75"(W) 18.63"(H) 17.13"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
| P-LPL-425-SS |
1/2" |
3/4" |
25' |
No |
300 |
39 |
7"(W) 18.63"(H) 17.13"(L) |
4"(M) 5"(N) |
6"(X) 6"(Y) |
What Our Experts Think
-
Stainless Steel Construction: Offers superior corrosion resistance, making it ideal for harsh, corrosive environments or outdoor use.
-
Low-Pressure Capability: Perfect for air, water, and light-duty fluid transfer, providing versatility across various industries like manufacturing, automotive, and agriculture.
-
Spring-Driven Retraction: Ensures smooth and automatic hose retraction, reducing manual effort and improving overall efficiency.
-
Heavy-Duty Design: Built to withstand frequent use and tough conditions, ensuring long-lasting performance.
-
Corrosion-Resistant Finish: Designed for high resistance to rust and wear, providing reliable performance in demanding environments.
-
Space-Efficient: Keeps hoses neatly stored and out of the way, maximizing workspace and improving safety in industrial settings.
Q&A
Q: What is the Coxreels SS Series "Stainless Steel" Low Pressure Spring Driven Hose Reel - P-LPL-335-SS?
A: The P-LPL-335-SS is a low-pressure, spring-driven hose reel made from durable stainless steel. Itās designed to provide reliable hose management with corrosion resistance for industrial and outdoor use.
Q: What is the hose capacity of this reel?
A: This reel can hold up to 335 feet of low-pressure hose, offering ample storage for a variety of applications.
Q: Why is stainless steel used in this reel?
A: Stainless steel construction enhances durability and corrosion resistance, making the reel suitable for harsh environments, including outdoor and marine settings.
Q: How does the spring-driven mechanism work?
A: The reel features a spring-driven rewind system that allows the hose to automatically retract for easy storage and organization.
Q: How is this reel mounted?
A: The reel can be mounted on walls, ceilings, or service vehicles, offering flexible installation options for various work environments.
Q: What are typical applications for this reel?
A: Perfect for light fluid transfer in industries like agriculture, automotive, or service vehicles, where low-pressure hose management is needed.
Maintenance Tips
-
Model: P-LPL-335-SS
-
Hose Capacity: Holds up to 100 feet of 3/8ā or 1/2ā low-pressure hose
-
Pressure Rating: Rated for low-pressure applications up to 300 PSI
-
Construction: Stainless steel frame for superior corrosion resistance and durability, ideal for harsh environments
-
Drive Mechanism: Spring-driven automatic rewind for smooth, effortless hose retraction
-
Swivel Inlet: Full-flow brass swivel ensures unrestricted fluid transfer with minimal wear
-
Roller Design: Multi-position guide arm with reinforced rollers for consistent hose payout and retraction
-
Mounting Type: Wall, floor, or ceiling mount for flexible installation options
-
Applications: Perfect for low-pressure fluid and air transfer in marine, chemical, pharmaceutical, and other industries requiring high resistance to corrosion
-
Temperature Range: Performs efficiently across a wide range of temperatures
-
Weight: Varies based on hose configuration and reel setup
