The Proline XE Condensing Ultra-Low NOx series with X3 Scale Prevention Technology is well suited for residential applications. State has combined water heating and treatment in a product designed to revolutionize tankless water heating. Their new condensing gas tankless line features X3 Scale Prevention Technology to last three times longer than other tankless models without X3 Technology.
The GTS-340HX3-NIH tankless water heater uses up to 180,000 BTU/hr of natural gas to deliver an endless supply of hot water for a 2.5 bath home in northern climates and up to a 3.5 bath home in southern climates (one shower head per bath).
X3 Scale Prevention Technology
No annual descaling required
No scale buildup means the heater lasts 3 times longer than competiros and maintains like-new performance longer
Primary heat exchanger is constructed of a commercial-grade copper that is more resilient to corrorsion than other materials
Secondary heat exchanger is made of 316L Stainless Steel to protect against corrosion
Qualified as lead free under the Safe Drinking Water Act
Exhaust and water temperature safety controls
Overheat cut-off fuse
Air-fuel ratio (AFR) sensor
Internal freeze protection system
Tankless water heaters with X3 Technology are approved to work with an external recirculation pump and cross-over valve
This unit comes with a 15-year limited warranty on the heat exchanger when used in residential application. It also comes with a 5-year limited warranty on all parts. Additionally, this unit has no hardwater exclusions in the industry’s first “peace of mind” limited warranty.
Type | Tankless Water Heater |
---|---|
Product Line | Proline XE Tankless Series |
Medium | Hot Water |
Fuel Type | Natural Gas |
Combustion Type | Condensing |
Vent Type | Direct Vent |
Storage Type | Tankless |
Mount Type | Wall |
Installation Location | Indoors |
Includes Recirculation Pump | No |
LP Kit | No |
Performance | |
Maximum Input Capacity | 180,000 BTU/h |
Minimum Input Capacity | 15,000 BTU/h |
Flow Rate at 40°F | 8.0 Gallons |
Flow Rate at 45°F | 7.6 Gallons |
Flow Rate at 50°F | 6.8 Gallons |
Flow Rate at 60°F | 5.7 Gallons |
Flow Rate at 70°F | 4.9 Gallons |
Uniform Energy Factor | 0.95 |
Minimum Flow Rate | 0.4 Gallons |
Ultra Low NOx Compliant | Yes |
Electrical Details | |
Voltage | 120 V |
Phase | 1 |
Frequency | 60 Hz |
Dimensions | |
Gas Connection Size | 3/4" |
Cold Water Inlet | 3/4" |
Hot Water Inlet | 3/4" |
Product Height | 23-5/8" |
Product Width | 17-3/4" |
Product Depth | 11-1/4" |
Product Weight | 72 lbs |
Exhaust Diameter | 3" or 4" |
