American Range Gas Griddles - ARMG-48-24
Countertop • 120,000 BTU • 1" polished steel plate • Made in USA
Engineered for high-volume kitchens, the American Range ARMG-48-24 pairs a massive 48" wide cooking zone with four powerful U-shaped burners for lightning-fast recovery and perfectly even heat. From breakfast rush to late-night service, this rugged stainless steel griddle keeps your line moving and your food sizzling.
Features
- 48" W x 24" D (1,152 sq in) cooking surface handles multiple menu items at once.
- Polished 1" (25 mm) thick steel plate for superior heat retention and easy cleaning.
- Four independent 30,000 BTU U-shaped burners (one every 12") deliver a total of 120,000 BTU/hr.
- Front-mounted manual gas valves give chefs instant temperature control.
- 3" welded splash guard and extra-wide 6¼" landing ledge keep work stations clean and safe.
- Full-width 3" stainless grease trough drains to a removable, easy-empty grease pan.
- All-stainless exterior (front, sides, landing ledge & splash) stands up to daily abuse.
- 4" adjustable stainless steel legs level the unit on any countertop.
- ¾" NPT rear gas connection — field convertible for Natural or LP gas (specify at checkout).
- ETL Sanitation & Gas certified; designed and built in California, USA.
Specifications
| Manufacturer |
American Range |
| Model # |
ARMG-48-24 |
| Gas Type |
Natural or LP (field convertible) |
| Total Input |
120,000 BTU/hr (35.0 kW) |
| Burners |
4 U-shaped, 30,000 BTU each |
| Cooking Surface |
48" W x 24" D, 1" thick polished steel |
| Overall Dimensions |
48" W x 35" D x 17" H |
| Splash Guard |
3" rear & sides (welded) |
| Grease Management |
3" trough with removable pan |
| Legs |
4" adjustable stainless steel |
| Gas Connection |
¾" NPT (rear, right-hand) |
What our Experts Think
Q&A
Q: What is the American Range ARMG-48-24 used for?
A: The American Range ARMG-48-24 is a 48-inch commercial gas griddle designed for high-volume kitchens that need a large flat cooking surface for breakfast service, burgers, sandwiches, and all-day griddle cooking.
Q: How powerful is the ARMG-48-24?
A: It delivers 120,000 BTU total output through four U-shaped burners, providing fast heat recovery and consistent performance across the full surface.
Q: What is the cooking surface size?
A: It features a 48-inch wide by 24-inch deep cooking area, offering a large workspace for batch cooking and multi-item preparation.
Q: What type of griddle plate does it use?
A: It uses a 1-inch thick polished steel griddle plate designed for excellent heat retention, durability, and even cooking results.
Q: Does it have independent heat control?
A: Yes, each burner is controlled independently, allowing multiple heat zones across the cooking surface for different menu items.
Q: Is it suitable for commercial kitchens?
A: Yes, it is built with a stainless steel exterior and heavy-duty components designed for continuous restaurant and foodservice use.
Q: How is grease managed and cleaning handled?
A: It includes a front grease trough and a removable grease pan to efficiently collect drippings and simplify cleaning during busy service
