True Mfg. - General Foodservice STA1F-2HG-HC SPEC SERIES Reach-In Refrigerators & Freezers

True Mfg. - General Foodservice STA1F-2HG-HC SPEC SERIES Reach-In Refrigerators & Freezers

SPEC SERIES Freezer, reach-in, -10°F, one-section, (2) glass half doors with locks, cam-lift hinges, digital temperature control, (3) chrome shelves, LED interior lights, stainless steel front & sides, aluminum interior, 5" castors, R290 Hydrocarbon refrigerant, 3/4 HP, 115v/60/1-ph, 10.4 amps, NEMA 5-15P, cULus, UL EPH Classified, Made in USA

Drawings

• Aqsl_true_sta1f-2hg-hc_p.dwg
• Aqsl_true_sta1f-2hg-hc_s.dwg
• Aqsl_true_sta1f-2hg-hc_e.dwg
• Qf_true_sta1f-2hg-hc.zip

Documents

• Cutsheet
• Installation manual

Specifications

What our Experts Think

• Premium Construction: Crafted with a stainless steel front and sides, and aluminum interior, ensuring durability and ease of maintenance.

• Energy-Efficient Refrigeration: Utilizes R-290 hydrocarbon refrigerant, offering an eco-friendly solution with a global warming potential (GWP) of 3.

• Optimal Temperature Control: Maintains temperatures between -10°F to 0°F, suitable for frozen foods and ice cream.

• Enhanced Visibility: Equipped with LED interior lighting and two triple-pane glass half doors, providing clear product visibility while reducing energy consumption. WebstaurantStore

• User-Friendly Features: Includes self-closing doors with a 120° stay-open feature, cam-lift hinges, and magnetic door gaskets for a tight seal.

Q&A

Q: What is the True STA1F-2HG-HC SPEC SERIES Reach-In Freezer?
A: A high-performance, single-section reach-in freezer with two half glass doors, built for demanding commercial kitchens and premium food storage.

Q: What is its storage capacity?
A: Offers 27 cu. ft. of storage with three adjustable, heavy-duty chrome shelves and a spacious, easy-to-clean interior.

Q: Is it energy efficient?
A: Yes, ENERGY STAR certified with high-efficiency components and advanced insulation for reduced energy consumption.

Q: Where is it best used?
A: Ideal for commercial kitchens, restaurants, and institutions that require visible, organized, and consistent frozen food storage.

Maintenance Tips

• Disconnect the unit by unplugging the power cord.

• Remove the grill assembly by unscrewing the top screws on the louver grill.

• Access the condenser assembly and loosen the bolts anchoring it to the frame rails

• Brush off dust and dirt using a stiff bristle brush or compressed air.

• Clean the condenser fan blade by lifting the cardboard cover and brushing off dust.

• Vacuum the surrounding area to remove any remaining debris.

• Reassemble by sliding the condenser assembly back into place and securing the grill.

• Reconnect the unit and ensure the condenser is running properly.
