Hoshizaki 80" Wide Horizontal Slide Top Bottle Cooler - CC80
The CC80 Back Bar is a three section refrigerator with slide top doors and has all the right features. It boasts an impressive net capacity of 24.67 cubic feet, approx. (1150) 12oz. cans or (547) 20oz. bottles. The dependable 1/3 HP motor that powers the compressor at the left side of this unit that distributes air from left to right rather than from back to front. Side to side circular airflow ensures ice-cold products even when doors are opened regularly. Engineered to maintain food safe temperatures in +100°F kitchens. Plus the durable stainless steel slide top lids include locks, can be easily removed for loading or unloading product.
The stainless steel interior incorporates an interior floor drain for easy cleaning. While the black vinyl exterior front, sides and rear, plus a 18 gauge stainless steel top will endure for many busy years! The CC80 has an electronic controller with led display (°f or °c), it also includes (6) gray epoxy bin dividers. Optional kits: (-S) stainless steel exterior – Made to Order. Cabinet fits: (1150) 12oz. cans or (547) 20oz. bottles. The unit is ETL Safety (US & C) Listed, ETL Sanitation and includes a five years compressor warranty / three years parts and labor warranty.
Features
- Dimensions: 80″ W x 26.5″ D x 33.38″ H
- Net capacity of 24.67 cubic feet, approx. (1150) 12oz. cans or (547) 20oz. bottles
- Nominal Compres. of N/A BTU/hr at 1/3 HP
- Electrical consumption of N/A kWh/day at 2 Amps, 8 ft long cord with a 5 – 15P NEMA plug
- Engineered to maintain food safe temperatures in +100°F kitchens
- Includes bottle opener with cap catcher
- Three slide top lids with flush inset handles
- Includes (6) gray epoxy bin dividers
- Durable stainless steel slide top lids include locks, can be easily removed for loading or unloading product
- Front breathing, side mount refrigeration that distributes air from left to right rather than from back to front
- Black Vinyl exterior front, sides and rear, plus a 18 gauge stainless steel top
- Stainless steel interior
- R290 refrigerant
- Automatic “off cycle” defrost cycle
- Interior floor drain for easy cleaning
- Includes 6 gray epoxy bin dividers
- Cabinets walls and doors well insulated (1-1/2″ thick) and are designed to maintain interior temperatures between 33°F to 38°F
- Electronic controller with LED display (°F or °C)
- Optional kits: (-S) stainless steel exterior – Made to Order
- 115v/60/1, 8 ft. cord and plug
- Shipping Crate: 82.5″ L x 31.25″ D x 39″ H at 315 lbs
- Cabinet fits: (1150) 12oz. cans or (547) 20oz. bottles
- Five Years compressor warranty, Three Years parts and labor warranty
Specifications
| Brand |
Hoshizaki |
| Model Number |
CC80 |
| Weight |
315 lbs |
| Width |
80" |
| Depth |
26.5" |
| Height |
33.38" |
| Horse power |
1/3 HP |
| Exterior Finish |
black |
| Compressor Location |
side mounted |
| Compressor Style |
front breathing |
| Capacity (cu. ft.) |
24.67 |
| Temperature Range (°F) |
32°F – 38°F |
| 12 oz. Bottles Capacity |
30 cases |
| 12 oz. Cans Capacity |
48 cases |
| Voltage |
115 |
What Our Experts Think
-
High-Capacity Storage: 80” wide design holds a large volume of bottles and cans for busy bars and restaurants.
-
Reliable Cooling: Maintains consistent, ice-cold temperatures to keep beverages perfectly chilled.
-
Durable Construction: Stainless steel top and heavy-duty black exterior for long-lasting performance.
-
Easy Access: Smooth-glide sliding lids allow quick and efficient drink retrieval.
-
Energy Efficient: Eco-friendly refrigeration system helps reduce energy costs.
Q&A
Q: What is the Hoshizaki CC80 Bottle Cooler used for?
A: It provides refrigerated storage for bottled and canned beverages, ideal for bars, restaurants, and hospitality businesses.
Q: What are its dimensions?
A: The unit is 80 inches wide, offering ample storage capacity while fitting efficiently in bar or serving areas.
Q: How much storage capacity does it offer?
A: It features a large interior with adjustable dividers to organize and store a high volume of drinks.
Q: What are its key features?
A: The CC80 includes a durable stainless steel top, horizontal sliding lids, LED interior lighting, and an energy-efficient refrigeration system.
Q: What is the temperature range?
A: It maintains a consistent, food-safe temperature to keep beverages perfectly chilled and ready to serve.
Q: Is it energy efficient?
A: Yes, it features an energy-efficient compressor and eco-friendly refrigerant for cost-effective operation.
Q: Does it require professional installation?
A: While designed for easy setup, professional installation is recommended for optimal performance and longevity.
Maintenance Tips
-
Clean Condenser Coils: Remove dust monthly to ensure efficient cooling.
-
Inspect Door Gaskets: Check for cracks or wear to maintain a tight seal and prevent temperature loss.
-
Monitor Temperature: Keep at recommended settings for optimal beverage cooling.
-
Defrost as Needed: Prevent ice buildup to maintain proper airflow and efficiency.
-
Wipe Interior & Exterior: Use mild detergent to keep surfaces clean and sanitary.
