American Range Gas Griddles - ARSTG-48
1" Polished Steel Plate | 120,000 BTU | Made in USA
Tackle the breakfast rush, lunch line, or late-night service with the power and precision of the American Range ARSTG-48. This 48" thermostatic griddle delivers even heat across a generous 21" deep cooking surface while its rugged stainless-steel body stands up to the demands of a busy commercial kitchen.
Key Features
- 48" W x 21" D cooking surface provides about 1,008 sq in of usable space
- Four (4) U-shaped 30,000 BTU burners—one every 12"—for a total of 120,000 BTU/hr
- Modulating thermostats with standing pilots hold 250 – 500 °F in each heating zone
- 1" thick, highly-polished steel plate stores and distributes heat evenly for consistent results
- 4" stainless-steel rear splash and 3 3/4" side splashes help keep surrounding surfaces clean
- 3" spatula-friendly grease trough channels runoff to two removable stainless-steel drawers (4.5 qt capacity each) for fast, mess-free cleanup
- Heavy-gauge stainless-steel front, sides, and landing ledge with 4" adjustable legs
- Factory-supplied 3/4" rear gas connection and pressure regulator — choose Natural Gas or LP
- ETL & ETL Sanitation listed; designed and built in North Las Vegas, NV & Pacoima, CA
- Backed by a 2-year limited parts & labor warranty
Specifications
| Specification |
Details |
| Model |
ARSTG-48 |
| Gas Type |
Natural Gas or Liquid Propane (field convertible) |
| Total BTU |
120,000 BTU/hr |
| Burners |
4 U-shaped aluminized-steel burners (30,000 BTU each) |
| Control |
Modulating thermostats, 250 °F – 500 °F |
| Plate Thickness |
1" polished steel |
| Cooking Surface |
48" W × 21" D |
| Overall Dimensions* |
48" W × 32 9/16" D × 18 7/16" H |
| Working Height* |
12 9/16" with 4" legs retracted |
| Gas Inlet |
3/4" NPT (rear), pressure regulator included |
| Shipping Weight |
Approx. 468 lb |
| Certifications |
ETL, ETL-Sanitation (NSF-equivalent) |
| Warranty |
2-year limited, parts & labor |
What’s Included
- Factory-installed standing pilots & thermostats
- 3/4" gas pressure regulator (shipped loose)
- Two removable stainless-steel grease drawers
- Four 4" adjustable stainless-steel legs
- Owner’s manual & warranty registration card
Gas installation notice: This appliance must be installed and serviced by a qualified professional. Verify incoming gas pressure matches factory specifications and provide adequate ventilation in accordance with local codes.
Need a different size? The American Range ARSTG series is available in widths from 12" to 72".
What Our Experts Think
-
The ARSTG-48 is a 48-inch countertop gas griddle designed for heavy-duty commercial use.
-
Its polished steel griddle plate ensures even heat distribution, making it ideal for cooking pancakes, burgers, eggs, and more.
-
Featuring multiple high-BTU burners, each with independent controls, it provides precise temperature management across the full 48-inch surface.
-
With a stainless steel body and durable construction, it’s built to handle continuous, high-volume cooking in restaurants, diners, and catering kitchens.
Q&A
Q: What is the size of the cooking surface?
A: The 48-inch wide surface gives ample space for handling multiple orders at once.
Q: Can I control heat zones independently?
A: Yes, each burner has its own control for flexible cooking zones.
Q: Is it suitable for high-volume kitchens?
A: Absolutely, the heavy-duty build and large surface make it ideal for busy operations.
Maintenance Tips
-
Scrape and wipe down the griddle after each use to prevent food buildup.
-
Season the griddle plate regularly to maintain performance and prevent rust.
-
Empty and clean the grease drawer daily.
-
Check burner flames for consistency and clean ports if necessary.
-
Use stainless steel-safe cleaners on exterior surfaces to maintain its professional look.
