Coxreels Fuel Dispensing Low Pressure Reels - S-5100LPF
Fuel Dispensing Low Pressure Reels
COXREELS Fuel Dispensing Reels are designed to handle various non-aromatic fuel applications including diesel, kerosene, fuel oil and heating oil. Coxreels professional fuel dispensing reels are an essential component found in utility, ground support, and bulk liquid handling transport services mounted on fuel storage & dispensing systems, fuel/lube trucks, aircraft refuelers, and tank trucks. The convenient uncoiling systems with the added hose control allow the operator to efficiently handle fuel transfers.
- Professional grade heavy duty steel construction
- Rolled edges & ribbed discs provide strength & safety
- Leading 2-year manufacturer's limited warranty
- Made in the U.S.A. - Sold & Supported Worldwide
Features
- SWIVEL - Machined from solid brass 90º full-flow NPT swivel for fuel dispensing applications.
- CARTRIDGE MOTOR - Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance.
- CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
- BOX-STYLE DESIGN - Sturdy box-style, reinforced steel frame design provides maximum strenght and stability.
- STEEL ROLLERS - Heavy duty 1" stainless steel pinch-proof rollers.
- OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish, and sturdy permanently lubricated precision bearings.
Specifications
| MODEL |
I.D |
O.D |
LENGTH |
HOSE |
MAX PSI |
SHIP WEIGHT (LBS) |
OVERALL DIMENSIONS (W) (H) (L) |
MOUNTING PATTERN (M) (N) |
BASE (X) (Y) |
| SLPF-5100 |
3/4" |
1 3/16" |
100' |
Yes |
300 |
107 |
19.63"(W) 20.5"(H) 22.88"(L) |
14"(M) 22"(N) |
15.38"(X) 25"(Y) |
| SLPF-550 |
3/4" |
1 3/16" |
50' |
Yes |
300 |
107 |
19.63"(W) 20.5"(H) 22.88"(L) |
14"(M) 18.5"(N) |
15.38"(X) 21.5"(Y) |
| SLPF-575 |
3/4" |
1 3/16" |
75' |
Yes |
300 |
107 |
19.63"(W) 20.5"(H) 22.88"(L) |
14"(M) 22"(N) |
15.38"(X) 25"(Y) |
| SLPF-625 |
1" |
1 1/2" |
25' |
Yes |
300 |
142 |
19.63"(W) 24.5"(H) 26.38"(L) |
14"(M) 18.5"(N) |
15.38"(X) 21.5"(Y) |
| SLPF-650 |
1" |
1 1/2" |
50' |
Yes |
300 |
142 |
19.63"(W) 24.5"(H) 26.38"(L) |
14"(M) 22"(N) |
15.38"(X) 25"(Y) |
| SLPF-675 |
1" |
1 1/2" |
75' |
Yes |
300 |
142 |
19.63"(W) 28.5"(H) 26.38"(L) |
14"(M) 22"(N) |
15.38"(X) 25"(Y)
|
What Our Experts Think
-
Low Pressure Design: Perfectly suited for fuel dispensing systems that require low-pressure operation, ensuring safe fluid transfer.
-
Corrosion-Resistant Construction: Made with durable materials that resist the harsh effects of fuel and other chemicals, ensuring longevity.
-
Heavy-Duty Performance: Built to withstand tough work environments, providing reliable service for years.
-
Smooth Hose Retraction: Features a spring-loaded mechanism for easy and tangle-free hose management, reducing downtime.
-
Versatile Use: Ideal for fueling stations, agriculture, and fleet maintenance, where safe and efficient fuel transfer is critical.
Q&A
Q: What is it?
A: A low-pressure fuel dispensing hose reel designed for safe, efficient handling and dispensing of fuels in industrial, commercial, and automotive environments.
Q: Who is it for?
A: Perfect for fueling stations, fleet maintenance, and industrial settings where low-pressure fuel dispensing is required.
Q: Why choose this reel?
A: Provides a safe, durable, and efficient solution for managing fuel hoses, reducing clutter and wear while improving productivity in fuel dispensing applications.
Maintenance Tips
-
Inspect Regularly: Check for leaks, wear, and loose fittings.
-
Hose Care: Avoid kinks, abrasions, and store properly.
-
Lubricate Bearings: Apply light lubricant for smooth operation.
-
Test Rewind Mechanism: Ensure proper spring tension and retraction.
-
Secure Mounting: Tighten bolts and check stability.
-
Clean Often: Remove fuel residue, dirt, and debris.
-
Use Correct Fluids: Ensure compatibility to prevent damage.
