DYNABRADE Right Angle Mini-Dynorbital Random Orbital Sander - 53417
-
.4 hp, 3,200 RPM, 3/16" (5 mm) Dia. Orbit, Rear Exhaust, for 1/4"-20 Female Pads.
- Built-in speed regulator, rear exhaust muffler, lever throttle. Heavy duty gear head. Includes sample 9-micron micro-finishing film discs. Optional 54585 Side Handle Assembly available.
-
54028 Random Orbital Sanding Head accepts sanding pads with 1/4"-20 female thread.
-
Includes 1-1/4" dia. medium density locking-type pad (54018), which has 1/4"-20 female thread which mounts to sanding head.
Specifications
| Air Consumption (SCFM) |
21.0 |
| Power (hp) |
0.4 |
| Max. RPM |
3,200 |
| Pad Face |
Vinyl |
| Tool Spindle Thread |
3/8-24 Male |
| Exhaust Type |
Rear |
| GL_Country Of Origin |
US |
| Hose I.D. in. (mm) |
1/4" |
| Vacuum Type |
Non-Vacuum |
| Motor Type |
Rotary Vane |
| Height in. (mm) |
2.75 |
| Length in. (mm) |
7.0 |
| Weight lb. (kg) |
3.97 |
| Width in. (mm) |
7.0 |
| Pkg. Height in. (mm) |
6 |
| Pkg. Length in. (mm) |
13 |
| Pkg. Weight lb. (kg) |
5.07 |
| Pkg. Width in. (mm) |
7 |
| CE Certified |
Yes |
| EAN (UPC) |
0616026534650 |
| EAC Certified |
Yes |
| Tool Style |
Right Angle |
What our Experts Think
-
Precise Sanding: Features a 3/16" (5 mm) orbit, ideal for fine finishes on metal, wood, and composites.
-
Compact & Lightweight: Weighs 1.9 lbs (0.86 kg), offering excellent control and reduced operator fatigue.
-
High-Speed Performance: Operates at 3,200 RPM, delivering efficient material removal for detailed work.
-
Ergonomic Design: Right-angle configuration and palm-style grip ensure comfort during extended use.
-
Versatile Compatibility: Includes 54028 sanding head, accepting 1/4"-20 female-threaded sanding pads.
-
Quiet Operation: Rear exhaust system and low noise level (81–84 dB(A)) contribute to a quieter work environment.
-
Durable Build: Constructed for longevity, suitable for both professional and DIY applications.
Q&A
Q: What type of sander is the Dynabrade 53417?
A: It’s a right-angle mini random orbital sander designed for tight and angled spaces.
Q: What is the sanding pad size?
A: Equipped with a 2" diameter sanding pad for precise sanding.
Q: What power source does it use?
A: The sander is pneumatic (air-powered), requiring an air compressor.
Q: What applications is the 53417 best suited for?
A: Ideal for sanding, finishing, and blending in hard-to-reach areas.
Q: Does it offer variable speed control?
A: Yes, it features variable speed for enhanced sanding control.
Maintenance Tips
-
Clean Regularly: Use compressed air to clear dust and debris from vents and moving parts after each use.
-
Check Sanding Pads: Replace worn or damaged pads to maintain sanding quality.
-
Lubricate Daily: Apply pneumatic tool oil to the air motor to ensure smooth operation.
-
Maintain Air Supply: Use clean, dry, and regulated air at 90 PSI max to avoid tool damage.
-
Inspect & Tighten: Periodically check and tighten all screws and fittings.
