U.S Industrial Grizzly Industrial 19" 3 HP Extreme-Series Bandsaw with Motor Brake - G0514X2B
A fully-featured 19" bandsaw with serious capabilities.
The G0514X2B 19" 3 HP Extreme-Series Bandsaw is ready to handle your woodworking projects.
The table will tilt 5° left and 45° right to provide a wide range of cutting options. The positive stop allows thew table to be quickly and accurately returned to 0°.
This saw features a rack-and-pinion table tilt control with extra table support and an innovative resaw fence. The cast-iron table trunnions add additional weight for greater stability.
The electronic motor brake stops the blade in approximately 3 seconds—all with the simple push of a switch.
A clear blade tracking window allows you to observe the blade as you adjust the tracking controls to center the blade. For a full range replacement and resaw blades for the G0514X2B, shop here.
Additional features include a heavy-duty miter gauge, dual 4" dust ports to suck up all the sawdust, and double ball-bearing blade guides that are usually found on machines costing much more.
Like all Grizzly bandsaws, the G0514X2B comes with a 1-year warranty which covers parts and assures the unit is free from factory defects.
The G0514X2B manual was written by our U.S. based Technical Documentation Department and is packed with useful information. The complete and easy-to-read manual provides full instructions on how to assemble and maintain your bandsaw.
The Grizzly Customer Service and Technical Support Teams are U.S. based. Parts and accessories for the bandsaw may be available online and shipped from the Grizzly parts warehouse in Springfield, MO.
Made in an ISO 9001 factory
Features
- Ball bearing blade guides
- Blade tension indicator
- Blade tracking window
- Quick change blade release/tensioning
- Fence with scale and magnifying window
- Micro adjusting geared table tilting mechanism
- Height scale measurement
- Deluxe cast-iron fence with extruded aluminum re-saw fence
- Computer Balanced cast-iron wheels with Grizzly bear head cut-outs
- Miter gauge
- Rack-and-pinion upper guide adjustment
- Rack-and-pinion table tilt mechanism
- Motor brake
- Cast-iron trunnion
- Includes 3/4" blade
Specifications
| Motor |
3 HP, 220V, single-phase, 12A |
| Cutting Capacity/Throat |
18-1/4" |
| Maximum Cutting Height |
12" |
| Table Size |
26-3/4" x 19" x 1-1/2" thick |
| Table Tilt |
5° left, 45° right |
| Floor to Table Height |
37-1/2" |
| Blade Size |
143" long |
| Blade Widths Available |
1/8"–1-1/4" |
| Blade Speeds |
1700, 3500 FPM |
| Blade Guides |
Dual ball bearing with full enclosure protection |
| Overall Size |
76" H x 36" W x 32" D |
| Approximate Shipping Weight |
512 lbs. |
What our Experts Think
-
Powerful Cutting Performance – 3 HP motor delivers smooth, precise cuts through hardwoods and thick stock.
-
19" Cutting Capacity – Handles large resawing and intricate curve-cutting tasks with ease.
-
Motor Brake for Safety – Stops the blade quickly, enhancing operator protection.
-
Heavy-Duty Construction – Cast-iron frame and precision-balanced wheels ensure stability and durability.
-
Perfect For – Professional woodworkers and serious hobbyists needing industrial-grade resawing and detailed cutting capabilities.
Q&A
Q: What is the U.S. Industrial Grizzly 19" 3 HP Extreme-Series Bandsaw with Motor Brake (G0514X2B)?
A: A heavy-duty 19-inch bandsaw with a 3 HP motor and motor brake, designed for high-precision cutting in professional woodworking shops.
Q: What is the motor power and voltage?
A: Equipped with a 3 HP, 220V single-phase motor, providing powerful and consistent cutting performance for hardwoods, softwoods, and composites.
Q: What is the cutting capacity?
A: - Maximum cutting height (resaw capacity): 14 inches
Q: What type of blade does it use?
A: - Accepts blades from 1/8" to 1-1/4" wide, offering versatility for fine detail work to heavy-duty resawing.
Q: What is the advantage of the motor brake?
A: The foot-operated motor brake allows for rapid blade stoppage, enhancing safety in the workshop.
Q: What kind of fence system does it include?
A: Comes with a precision aluminum resaw fence for accurate, repeatable cuts.
Q: Does it have dust collection?
A: Yes, features dual 4-inch dust ports for efficient dust extraction.
Q: Why choose this bandsaw?
A: Its large cutting capacity, powerful motor, motor brake for safety, precision fence, and industrial-grade build make it an excellent choice for serious woodworkers and professionals.
Maintenance Tips
-
Blade Care: Regularly inspect, tension, and replace the blade for precise cutting.
-
Wheel & Tire Maintenance: Clean and check for wear; replace tires if cracked or worn.
-
Guide Bearings & Blocks: Keep clean and lubricate as needed for smooth operation.
-
Table & Fence Alignment: Ensure the table and fence are square for accurate cuts.
-
Dust Collection System: Keep ports clear and empty dust bins frequently.
-
Motor & Brake Inspection: Test the motor brake function and inspect wiring for safety.
-
Belt & Pulley Check: Ensure proper tension and replace worn belts.
