Hydra-Kool - Commercial - 117" Full Service Fresh Meat Deli Case, Self-Contained - KFM-FG-120-S
This KFMCG120S curved glass deli case with self contained refrigeration by Hydra-Kool is designed for fresh meat, featuring tilt out curved tempered front glass and sliding doors.
Features
Features
- CFC free injected foam insulation
- Stainless steel interior
- Stainless steel rear work bench
- Silver colored PVC coated steel front panel
- Black steel kick plate
- Foamed polystyrene black end panels
- Tempered tilt-foward front glass
- Removable rear tempered glass sliding doors
- LED lighting in canopy
- Temperature and defrost regulated by a digital controller
- Removable condensate evaporating pan for easy cleaning on self contained units
- Slide out condensing unit on self-contained units
- Digital thermometer
- Levelling feet
- Stainless steel exterior
- Lift up front glass
- Other colors available
- Joining Kit
- Partition
- Condensate evaporating pan for remote cases
- White epoxy bi-level wire racks; 2 or 3 level step sham
- Scale stand with receptacle
- Cutting board
- Knife Supprt
- Casters add 4-3/8” to height
- Stainless steel legs are adjustable from 5-1/8” to 7-5/8”
Specifications
Specifications
| Brand |
Hydra‑Kool |
| Model / Product Number |
KFM‑CG‑120‑S |
| SKU |
KFMCG120S |
| UPC |
6997390003336 |
| Stock ID |
735186 |
| Condition |
Brand New |
| Type |
Deli Case |
| Sections |
1 |
| Color |
Black |
| Door Style |
Sliding |
| Glass Style |
Curved |
| Compressor Location |
Bottom |
| Capacity |
37.76 cu. ft. |
| LED Lighting |
Yes |
| Revolving Shelves |
No |
| Convertible Baffle |
No |
| CFC Free |
Yes |
| Pass‑Through |
No |
| Horsepower |
3/4 HP |
| Installation Type |
Freestanding |
| Temperature Range |
32 °F – 40 °F |
| Amperage |
25 Amps |
| Hertz |
60 Hz |
| Phase |
1 |
| Voltage |
115 Volts |
| Exterior Width |
120″ |
| ETL Listed |
Yes |
| AHRI Certified |
No |
| NSF Certified |
No |
| CE Certified |
No |
| UL Listed |
No |
| Energy Star Rated |
No |
| ADA Compliant |
No |
| Weight |
999.99 lbs |
Dimensions & Weight
Dimensions & Weight
-
Width: 117"
-
Depth: 43.3125"
-
Height: 49.40625"
Downloads & Manual
Downloads & Manual
What our Experts Think
-
Premium Meat Display – Expansive 117" case showcases fresh meat for maximum customer appeal.
-
Consistent Temperature Control – Self-contained system ensures optimal freshness and food safety.
-
Spacious & Organized – Ample room for multiple meat cuts with easy access for staff.
-
Durable Commercial Build – Designed to withstand heavy use in high-traffic deli environments.
-
Easy Cleaning & Maintenance – Removable trays and accessible components simplify daily upkeep.
-
Energy-Efficient Operation – Advanced cooling technology reduces power usage while maintaining product quality.
Q&A
Q: What is the Hydra-Kool KFM-FG-120-S?
A: A 117" commercial full-service deli case for fresh meat, self-contained, designed for retail and foodservice environments.
Q: What are its main features?
A: Self-contained refrigeration, energy-efficient LED lighting, full-service display with sliding doors, and durable stainless-steel construction.
Q: What type of business is it ideal for?
A: Butcher shops, grocery stores, delis, and restaurants displaying fresh meat products.
Q: How does it benefit businesses?
A: Maintains optimal meat freshness, enhances product visibility, and encourages customer purchases.
Q: What makes it commercial-grade?
A: Heavy-duty design, consistent cooling, and large-capacity display for high-volume operations.
Maintenance Tips
-
Clean all food‑contact surfaces (interior stainless steel, shelves, glass front and sides) daily using a mild, food‑safe detergent; rinse and dry thoroughly.
-
Remove product, and deep‑clean monthly: remove trays and racks, clean the evaporator drain pan, and clear any debris or blockages.
-
Keep the condenser coils, ventilation grilles and the pull‑out condensing unit free from dust and obstruction—build‑up reduces cooling efficiency.
-
Inspect door seals, sliding rear glass doors, and front glass assembly for wear, tears or poor fit—ensure a tight seal to prevent warm‑air ingress.
-
Verify the case temperature is maintained in the correct range (approximately 32‑40 °F) and that the digital defrost/temperature controller is functioning properly.
-
Ensure the case is level using its adjustable feet; uneven placement can impair drainage, door operation and airflow.
-
Avoid over‑loading product display area; allow for proper airflow behind and between items so cold air circulates evenly.
-
Turn off power before performing any major cleaning or component work (fans, coils, electrical panel) for safety.
