Hydra-Kool - Commercial - 101" Full Service Refrigerated Deli Display Case, Remote - KPM-CG-100-R
This KPMFG100R flat glass deli case with remote refrigeration by Hydra-Kool with tilt out flat tempered front glass and rear tempered sliding doors is designed for deli products and packaged meat.
Features
Features
- Insulation-injected foam
- Interior-PVC coated steel-Gray
- Exterior-PVC coated steel-silver
- Ends-foamed-black polystyrene
- Tilt- forward tempered front glass
- cases are multiplexible
- Tempered glass non-refrigerated shelf
- Pull-out condensing unit on S/C only
- Removable Rear Tempered Glass Sliding Doors
- Defrost and temperature regulated by a digital controller
- Removable evaporative pan for easy cleaning on S/C only
- LED lighting in canopy and under shelf
- Anti-condensate system for front glass
- Adjustable feet
- ETL listed to UL471 and Sanitation Classified to NSF7
- These cases comply with the National Energy Standards
Specifications
Specifications
| Brand |
Hydra-Kool |
| SKU |
KPMFG100R |
| Stock ID |
735593 |
| Product Number |
KPM-FG-100-R |
| Type |
Deli |
| Color |
Black |
| Compressor Location |
Bottom |
| LED Lighting |
Yes |
| Revolving Shelves |
No |
| Amps |
15 Amps |
| Hertz |
60 Hz |
| Voltage |
115 Volts |
| Exterior Width |
100" |
| ETL Listed |
Yes |
| Cooling BTU |
4372 BTU |
| Weight |
866 lbs |
| AHRI Certified |
No |
| Energy Star |
No |
| ADA Compliant |
No |
Dimensions & Weight
Dimensions & Weight
-
Width: 101.125"
-
Depth: 43.375"
-
Height: 47.25"
Downloads & Manual
Downloads & Manual
What our Experts Think
-
Large Full-Service Display: The Hydra-Kool KPM-CG-100-R features a 101" curved-glass case, providing ample space for fresh meat and deli products.
-
Remote Refrigeration: Keeps condensing units separate from the display area, reducing noise and heat for a better customer environment.
-
Premium Construction: Stainless-steel interior, tempered curved glass, and rear sliding doors offer durability and professional presentation.
-
Optimal Freshness: Maintains 33–40°F, ensuring meat and deli items stay safe and high-quality.
-
Commercial Reliability: Foam-injected insulation, LED canopy lighting, and adjustable feet support daily heavy use and long-term performance.
-
Service-Friendly Design: Rear access allows efficient stocking and full-service operation.
Q&A
Q: What is the Hydra-Kool KPM-CG-100-R?
A: A 101" full-service refrigerated deli display case with remote refrigeration, designed for fresh meat, packaged deli items, and high-visibility commercial display.
Q: What type of refrigeration does it use?
A: Remote condenser system with digital temperature and defrost control for consistent cooling.
Q: What are the key display and construction features?
A:
-
Tilt-forward curved tempered front glass and tempered glass sides for maximum product visibility.
-
Stainless steel interior, PVC-coated steel front panel, black kickplate and end panels.
-
LED canopy lighting to highlight displayed products.
-
Rear sliding tempered glass doors for service access.
Q: What are the dimensions and temperature range?
A: Width ~101.2″, Depth ~43.4″, Height ~49.4″; ideal temperature range 33–40 °F for fresh meat and deli items.
Q: Are there optional features or accessories?
A: Lift-up front glass, adjustable legs, stainless steel finishes, and joining kits for multi-unit runs. Multiplexable for long display lines.
Q: Where is it best used?
A: Supermarkets, butcher shops, full-service delis, and gourmet grocers needing a premium, high-capacity refrigerated display for meats and deli products.
Maintenance Tips
-
Clean interior and exterior surfaces daily with mild detergent to maintain hygiene and product presentation.
-
Wipe glass panels regularly using a non-abrasive cleaner for clear visibility.
-
Inspect and clean the remote condenser unit monthly to ensure efficient cooling and prevent dust buildup.
-
Check door gaskets and seals for wear or gaps to maintain consistent temperature.
-
Empty and sanitize the drain pan weekly to prevent clogs and odors.
-
Monitor temperature settings daily to keep products fresh and safe.
-
Schedule annual professional servicing to maintain optimal refrigeration performance.
