Fanuc Corporation | GE FANUC Speedtronic Turbine Control PCB Board - IS200GGXIG1A
The IS200GGXIG1A is a component board designed for integration within General Electric's Innovation Series board racks, specifically tailored for the Mark VI system. Developed as part of GE's longstanding Speedtronic line for gas and steam turbine management, the Mark VI system represents an evolution from earlier models like the Mark I, continuing through to the Mark VIe
The IS200GGXIG1A is a vital component of the Mark VI system manufactured by General Electric. Designed for integration within Innovation Series board racks, it serves as an Expander Load Source Board facilitating control and isolation between the high-voltage power bridge and connected cards like the BPII and BICI. This board plays a crucial role in converting RS422 signals to fiber-optic signals, essential for gating the bridge IGCT switching devices, thereby enhancing operational efficiency.Â
Featuring extensive connectivity options, the IS200GGXIG1A is equipped with multiple I/Os for seamless integration with other boards. It includes power supply inputs (J1 through J4), power output and feedback connectors (J10 through J12), voltage feedback (J15 and J16), and dedicated fiber-optic connectors. Specific board-to-board communications are facilitated through connectors like JFBK (BICI board), JGATE (BPII board), and J5 (GDPA board). To ensure operational reliability, the board incorporates grounding stabs (LCOM and DCOM) designed for both quiet and noisy circuits.Â
GE FANUC, now part of Emerson Automation Solutions, was a leading provider of industrial automation and control systems. Known for innovative solutions, GE FANUC played a key role in advancing manufacturing, offering a range of products including PLCs, CNCs, and HMI solutions.
SpecificationsÂ
Part Number |
IS200GGXIG1A Â Â Â |
Manufacturer |
General Electric    |
Series |
Mark VI Â Â Â |
Product Type |
Expander Load Source Board    |
Function |
Controls and isolates high-voltage power bridge connections    |
Signal Conversion |
Converts RS422 signals to fiber-optic signals    |
Maximum Power Devices |
Up to twelve    |
Â
What Our Experts Think
-
Precision Turbine Control: Manages critical turbine operations for stable and efficient performance.
-
Robust Design: Built to handle high-stress environments, ensuring reliable function in demanding industrial settings.
-
Seamless Integration: Easily integrates with Speedtronic turbine control systems for smooth operation.
-
Enhanced System Efficiency: Optimizes turbine control and response time, improving overall system performance.
-
GE FANUC Quality: Trusted for its durability, precision, and minimal maintenance requirements.
-
Designed for Long Life: Engineered to support long-term turbine operations with minimal downtime.
