Jabsco Par-Max HD6 Heavy Duty Water Pressure Pump - 24V - 6 GPM - 40 PSI [P602J-215S-3A] - CWR-86654

Jabsco Par-Max HD6 Heavy Duty Water Pressure Pump - 24V - 6 GPM - 40 PSI [P602J-215S-3A] - CWR-86654

Par-Max HD6 Heavy Duty Water Pressure Pump - 24V - 6 GPM - 40 PSI

HD (Heavy Duty) models include a wider diameter motor with a powder coated shell, cast aluminum endbells and lower housing to improve pressure capability and life. Available in configurations up to 6 GPM (23 LPM) and 60 PSI (4.1 BAR), these pumps deliver exceptional performance.

Standard models provide good performance in an economical footprint. These configurations are available in 1-3 GPM, perfect for vessels with 1-3 outlets. A plastic housing protects the motors on these units from corrosion.

Features

• Co-molded diaphragm technology for long life and durability
• HD models feature heavy duty, motors and cast aluminum lower housings which allow for longlife, even at high pressures
• Efficient and quiet operation
• Integrated, sealed pressure switch for on-demand operation
• Self-priming allows for installation versatility
• Can run dry without damage
• Quick connect ports for ease of installation, servicing, and maintenance
• Vibration dampening mounting feet
• Equipped with integrated bypass module to reduce cycling and provide smoother flow

Specifications

What our Experts Think

• Reliable Marine‑Grade Performance: Designed for marine and freshwater systems, this 24 V pressure pump delivers up to 6 GPM at ~40 PSI, giving steady, strong water pressure for sinks, showers, and appliances.

• Heavy‑Duty Build: The HD6 model features a wider motor, cast aluminum lower housing and co‑molded diaphragm technology for long life and durability even under sustained pressure.

• Smooth & Efficient Operation: Built‑in sealed pressure switch and bypass module reduce cycling and deliver smoother flow, while vibration‑dampening feet improve quiet performance.

• Versatile & Easy to Install: Self‑priming up to about 7 ft dry and equipped with quick‑connect ports, it supports flexible installation and easier servicing.

• Durable & Safe: EPDM check valves, rugged polypropylene housing and marine‑standard certifications (ISO 8846) mean dependable, corrosion‑resistant operation.

Q&A

Q1: What is the Jabsco Par-Max HD6 pump used for?
A1: A heavy-duty 24V water pressure pump for boats, RVs, and commercial systems, providing reliable pressurized water for sinks, showers, and deck wash.

Q2: What is the flow rate and pressure?
A2: Delivers 6 GPM at 40 PSI for consistent, high-volume water flow.

Q3: What voltage does it operate on?
A3: 24V DC, compatible with standard marine and industrial electrical systems.

Q4: Is it durable?
A4: Yes — built for long-lasting, corrosion-resistant operation in harsh marine and industrial environments.

Q5: Why choose the Jabsco Par-Max HD6?
A5: Combines heavy-duty 24V performance, 6 GPM flow, 40 PSI pressure, and durable construction, ideal for demanding marine and commercial water applications.

Maintenance Tips

• Inspect Pump & Housing: Check for leaks, cracks, or corrosion before use.

• Clean Inlet & Filters: Remove debris to maintain proper flow and prevent damage.

• Electrical Check: Inspect 24V wiring and connections for wear or corrosion; ensure secure power supply.

• Monitor Performance: Verify consistent water pressure (40 PSI) and flow rate (6 GPM); listen for unusual noises.

• Lubricate Moving Parts (if applicable): Follow manufacturer guidelines for smooth operation.

• Winterization: Drain water when storing in freezing conditions to prevent damage.

• Secure Mounting: Ensure pump and components are tightly fastened.

• Routine Maintenance: Follow OEM schedule to maintain efficiency and extend lifespan.
