Marshall Electronics CV730-NDIW UHD 4K Broadcast PTZ Camera with NDI|HX - CV730NDIW
Marshall CV730-NDIW highlights a 30x optical zoom block and convenient multiple 12GSDI and HDMI outputs with NDI®|HX2. and amazingly clear UHD images up to 3840x2160p at 60fps. NDI®|HX2. provides low latency, excellent quality, frame-accurate video, and audio in real time to IP workflows. NDI® Tools opens the capability to incorporate more video devices and applications into your production workflow. CV730-NDIW is the first UHD60 PTZ camera with NDI®|HX2..
Best of Class
Featuring 12GSDI, HDMI2.0, and NDI®|HX2. from a professional level 8.5MP 1/1.8" UHD sensor and smooth synchronous movements. CV730-NDIW is the first to deliver UHD60 performance with NDI®|HX2. ease-of-use delivering crystal-clear images up to 3840x2160p at 60fps. NDI®|HX2. provides Video, Audio, Control, Tally and Power over one Ethernet cable for remote broadcast-style adjust & match settings control
Flexible Zoom Range
Constructed with a precision 30x optical zoom range starting at just under 65° horizontal angle-of-view at 6.5mm all the way out to 202mm which captures a crystal clear head & shoulder shot at very long distances.
Ease of Use
Install one-cable to camera with NDI®|HX2. for all functions, simple connect to any Ethernet port - THAT'S IT - or use Ethernet for PoE++/Preview and other outputs (12GSDI/HDMI) for simultaneous workflows for streaming, production, or archiving.
Professional Broadcast Performance
Marshall Camera Division continues to develop cutting edge camera products to follow the heritage of Marshall broadcast quality incorporating reliability, durability, flexibility and most importantly affordability with feature sets that matter to our industry partners. CV730-NDIW constitutes the World's first NDI®|HX2. PTZ camera with Ultra-HD video quality at 60fps.
Features
- Video Resolution up to UHD 4K60
- 6.5 to 202mm Lens, 30x Optical Zoom
- 12G-SDI, HDMI 2.0, and NDI|HX Outputs
- 65° AoV, PoE, Tally Support
- RS-232 & RS-422 Serial Control
- VISCA and Pelco-D Protocol Support
- IR Remote Included
- 8.5 Megapixel UHD Sensor (1/1.8")
- 30x optical zoom (6.5mm~202mm) starting at 65° H.AOV
- 340° pan & 120° tilt range with select-able transition speeds (5~300° per second)
- 12G/6G/3G-SDI, HDMI2.0, USB3.0 and NDI®|HX2. simultaneous outputs
- 3840x2160p (UHD), 1920x1080p (HD), 1920x1080i (HD) & 1280x720p
- 59.94, 50, 29.97, 25fps options up to 4K60 and HD60
- 3.5mm TRS Stereo Audio over I/O cable (Mic/Line)
- 12V Power Supply included and PoE++ (IEEE802.3bt)
What Our Experts Think
-
Ultra HD 4K Resolution – Captures stunning 4K UHD (3840x2160) video at 60fps, delivering exceptional clarity and detail.
-
NDI|HX Streaming – Supports low-latency, high-quality video transmission over IP networks for seamless integration.
-
30x Optical Zoom – Provides powerful zoom capabilities for detailed close-ups in live broadcasts and productions.
-
Smooth PTZ Control – Offers precise pan, tilt, and zoom functions with remote operation for professional versatility.
-
Flexible Connectivity – Features NDI|HX, 3G-SDI, HDMI, and IP streaming for maximum workflow compatibility.
-
Low-Light Performance – Advanced HDR and noise reduction ensure high-quality images in various lighting conditions.
-
Ideal for Broadcast & Live Events – Perfect for studios, houses of worship, corporate events, and esports productions.
Q&A
Q: What is the Marshall Electronics CV730-NDIW UHD 4K Broadcast PTZ Camera?
A: The Marshall CV730-NDIW is a professional 4K PTZ camera designed for broadcast, live streaming, and video production. It features NDI|HX support, enabling high-quality, low-latency video transmission over IP networks.
Q: What is this camera used for?
A: It is ideal for broadcast studios, live events, houses of worship, corporate conferencing, and sports productions, providing smooth pan, tilt, and zoom capabilities for dynamic coverage.
Q: Does this camera support 4K resolution?
A: Yes, it captures UHD 4K video at up to 60fps, delivering crisp and detailed imagery.
Q: What is NDI|HX, and why is it important?
A: NDI|HX is a network-based video transmission protocol that allows for efficient, high-quality streaming with lower bandwidth usage, making it perfect for IP-based production workflows.
Q: Can this camera be controlled remotely?
A: Yes, it supports remote control via IP, RS-232, or RS-422, offering flexible integration into professional setups.
Maintenance Tips
-
Clean the Lens Carefully – Use a microfiber cloth and lens-safe cleaner to remove dust and smudges without scratching.
-
Ensure Proper Ventilation – Keep air vents clear to prevent overheating and maintain optimal performance.
-
Check Cable Connections – Regularly inspect power, network, and video cables for secure connections and signal integrity.
-
Update Firmware – Install firmware updates to enhance functionality, security, and compatibility with NDI|HX.
-
Protect from Power Surges – Use a surge protector or an uninterruptible power supply (UPS) to prevent damage from voltage fluctuations.
-
Avoid Extreme Conditions – Keep the camera away from excessive heat, humidity, and direct sunlight for prolonged longevity.
-
Test PTZ Functions – Periodically check pan, tilt, and zoom operations to ensure smooth movement and responsiveness.
-
Secure Mounting – Ensure the camera is properly mounted and stable to avoid vibrations or misalignment.
