| Parallelism and Flatness Accuracy |
less than 0.0008" |
| Max. Travel (Longitudinal x Cross) |
22” x 10.2” |
| Max. Distance Spindle Center To Table |
17.7” |
| Max Grinding Wheel (ODxTxID) |
200mm x 31.75mm x 20mm (Supplied with one 7” x ½” grinding wheel) |
| Grinding Wheel speed |
3360 rpm |
| Spindle Motor |
2HP |
| Hyd. unit Motor |
2HP |
| Machine weight |
2,300 lbs (Gross Shipping) |
| Dimension, crated for shipping |
48”W x 66.4”L x 73”T |
Package Includes
-
Semi Fine Pole Permanent Chuck, 9.8” x 19.7”
-
Wet coolant system
-
Touch Screen color LCD with DRO for cross/downfeed
-
Hydraulic reciprocation of table
-
Electric motorized crossfeed
-
Overwheel (Parallel) diamond dresser
What Our Experts Think
-
Advanced 3-Axis Control: The U.S. Industrial Machinery 3-Axis Automatic Surface Grinder (USG1022-AHD) features advanced 3-axis control, providing greater versatility and precision for complex grinding tasks. This allows for more intricate part geometries and enhanced surface finishes, perfect for industries such as aerospace, automotive, and high-precision manufacturing.
-
Larger Grinding Capacity: With a 10” x 22” grinding capacity, this grinder is ideal for medium-sized workpieces, making it well-suited for a wide range of applications. Its ability to handle larger parts provides flexibility for businesses that need to process a variety of workpiece sizes.
-
Improved Productivity: The 3-axis automatic system streamlines the grinding process, allowing operators to achieve precise and consistent results with less manual intervention. This automated functionality reduces the need for constant adjustments, leading to faster production times and higher overall efficiency.
-
Enhanced Surface Finish Quality: The USG1022-AHD excels in providing superior surface finishes on a variety of materials. The 3-axis movement allows for precise adjustments, reducing the potential for surface defects and ensuring high-quality results for precision tooling, molds, and finished parts.
-
User-Friendly Interface: Despite its advanced 3-axis system, the USG1022-AHD remains easy to operate. The intuitive control interface and programmable settings make it simple for operators to set up and adjust, minimizing downtime and reducing the need for extensive training.
-
Durable Construction for Heavy Use: Built with a robust frame and high-quality components, this surface grinder is designed for long-lasting durability and consistent performance, even under heavy daily use. The machine’s solid build ensures minimal vibration and maximum stability during operation.
-
Versatile Grinding Applications: The USG1022-AHD can grind a variety of materials, including metals, composites, and plastics, making it highly versatile for a range of industries. Its adaptability increases its value for businesses involved in diverse production processes.
-
Cost-Effective Investment for Long-Term Use: While the initial cost is higher compared to more basic models, the USG1022-AHD offers excellent value through its advanced features and long-term durability. Its ability to improve productivity and deliver consistent, high-quality results makes it a smart investment for businesses that require frequent, precision grinding.
Q&A
Q: What is the U.S. Industrial Machinery 3-Axis Automatic Surface Grinder, 10” x 22” - USG1022-AHD?
A: The U.S. Industrial Machinery USG1022-AHD is a 3-axis automatic surface grinder designed for precise surface grinding applications. With a 10” x 22” work surface, it is ideal for grinding metal surfaces with high accuracy and consistent results.
Q: What are the key features of the USG1022-AHD?
A: The USG1022-AHD features a 10” x 22” grinding area and a 3-axis automatic control system, allowing for enhanced precision and versatility. It is equipped with high-powered motors and a durable construction, offering reliable performance for various grinding needs.
Q: What materials can the USG1022-AHD handle?
A: The USG1022-AHD is capable of grinding a wide range of metals, including steel, aluminum, and other alloys. It is commonly used for tool sharpening, metal fabrication, and achieving smooth, flat finishes on flat metal surfaces.
Q: What are the dimensions and weight of the USG1022-AHD?
A: The USG1022-AHD features a 10” x 22” grinding surface. For complete details on its dimensions and weight, please refer to the product manual or contact the manufacturer for more specific information.
Q: Is the USG1022-AHD easy to operate?
A: Yes, the USG1022-AHD is designed for easy operation. Its 3-axis automatic control system makes it user-friendly and efficient, ensuring precision and minimal operator effort. This makes it suitable for both experienced operators and those new to surface grinding.
Q: Does the USG1022-AHD come with a warranty?
A: Yes, the USG1022-AHD typically comes with a manufacturer warranty. For more details on the warranty coverage, please contact the manufacturer or an authorized distributor directly.
Q: Who is the USG1022-AHD ideal for?
A: The USG1022-AHD is ideal for medium to large-scale metalworking shops, tool and die shops, and industries that require precise and high-quality surface grinding. Its larger work surface and 3-axis control make it perfect for a variety of metal surface finishing applications.
Maintenance Tips
-
Inspect Grinding Wheel: Check for wear, cracks, or damage regularly. Replace or resharpen the wheel as needed to ensure smooth, accurate grinding.
-
Lubricate Moving Parts: Apply grease to the table, saddle, and cross-feed mechanisms to reduce friction, extend life, and ensure smooth movement of the axes.
-
Clean the Machine: After every use, remove metal dust, coolant, and debris from the work surface, wheel head, and surrounding areas to maintain a clean operating environment.
-
Hydraulic System Maintenance: Monitor hydraulic fluid levels, check hoses for leaks, and replace hydraulic oil per manufacturer recommendations to ensure consistent force delivery.
-
Electrical System Inspection: Test the electrical components, such as switches and emergency stops, for proper functionality. Inspect wiring for wear or damage.
-
Check Bearings and Guides: Regularly inspect bearings and guides for wear and tear. Replace or adjust them as needed to maintain precision and smooth operation.
-
Tighten Fasteners: Periodically check all bolts, nuts, and screws to ensure they are secure, preventing vibrations and maintaining the stability of the machine.
-
Calibrate Alignment: Check and adjust the alignment of the grinding wheel and workpiece positioning to ensure precise grinding and consistent results.
-
Follow Manufacturer’s Maintenance Schedule: Stick to the recommended maintenance intervals for part replacements, oil changes, and system checks for optimal performance.
