U.S Industrial Machinery 2-Axis Automatic Surface Grinder, 12” x 24”, -USG1224-SY

FREE SHIPPING
CLEARANCE SALE
80 Peoples are also watching.
SKU: USG1224-SY
$23,490.99
$24,990.00
$23,490.99
Subtotal: $23,490.99
clearance sale ends in
00 Hours
00 Minutes
00 Seconds
authorized dealer, shop your favorite brand.
Expert Support,

Dial +1 (888) 575-2099

Limited Supply,

grab it before it's gone.

Lowest prices,

As low as possible.

All Items are brand New,

Never used.

U.S Industrial Machinery 2-Axis Automatic Surface Grinder, 12” x 24”,  -USG1224-SY

U.S Industrial Machinery 2-Axis Automatic Surface Grinder, 12” x 24”, -USG1224-SY

$24,990.00 $23,490.99

U.S Industrial Machinery 2-Axis Automatic Surface Grinder, 12” x 24”, -USG1224-SY

$24,990.00 $23,490.99

Recently Viewed Products

U.S. Industrial Machinery has you covered with all of the machinery to perform artistic metalworking jobs right down to the finish.

Our surface grinder inventory includes four models that offer varying levels of grinding but all provide the finish you need. Our company prides itself on the high level of customer service we provide each customer. This includes our ongoing support for you with your products, including our warranty, troubleshooting support, and traveling field technicians. Contact our team today to learn more about incredible equipment at some of the most competitive prices. Each one of our surface grinders includes a two-axis readout. Operation type varies by model number, but you can find a machine that offers all manual operation, electric reciprocating and electric cross, or hydraulic reciprocating and electric cross. Each one is capable of 220- or 440-volt 3-phase electric power. At our Memphis, Tennessee facility we complete the assembly, calibrate, test, and perform cosmetic upgrades of all in-coming machinery. We don’t let products leave our hands until we are fully confident that they surpass our high standards. This is a medium duty toolroom Surface Grinder with hydraulic reciprocation of table and electric motor power increment setting for crossfeed. There is power elevation to spindle. Grind depth is manually set by operator. This is a TWO-AXIS Automatic Surface Grinder.

  • Sino two-axis digital readout

  • Grinding wheel

  • Balancing base and arbor

  • Wheel dresser with diamond

  • Lube system

  • Permanent magnetic chuck

  • Wheel flange

  • Toolbox and tools

  • Coolant system

Parallelism and Flatness Accuracy <0.0008"
Max. Travel (Longitudinal x Cross) 24.8” x 12.6”
Max. Distance Spindle Center To Table 20.5”
Max Grinding Wheel (ODxTxID) 300mm x 76.2mm x 30mm (Supplied with one 12” x 1-1/4” grinding wheel)
Grinding Wheel speed 1680 rpm
Spindle Motor 3HP
Hyd. unit Motor 3HP
Machine weight 3400 lbs. (Gross Shipping)
Dimension, crated for shipping 56”W x 72”L x 76”T
  • Semi Fine Pole Permanent Chuck, 11.8” x 23.6”

  • Wet coolant system

  • Sino two axes DRO installed

  • Hydraulic reciprocation of table

  • Electric motorized crossfeed

  • Power elevation to spindle

  • Overwheel (Parallel) diamond dresser

  • Superior Precision and Finish: The U.S. Industrial Machinery 2-Axis Automatic Surface Grinder (USG1224-SY) is designed to provide exceptional surface finishes and high precision, making it perfect for applications that require tight tolerances and smooth surfaces, such as precision tooling and aerospace components.
  • Automatic 2-Axis Control: The automatic 2-axis control system ensures consistent and reliable grinding results with minimal operator involvement. This feature reduces the potential for human error and enhances repeatability, making it ideal for high-volume or production environments.
  • Larger Grinding Capacity: With a 12” x 24” grinding capacity, this machine can accommodate larger workpieces, providing flexibility for a wide range of applications. It is perfect for industries that require larger parts, such as automotive, manufacturing, and mold-making.
  • Enhanced Productivity: The automated functions of the USG1224-SY significantly improve productivity by reducing setup times and enabling longer, uninterrupted operation. Operators can focus on other tasks while the grinder continues working, increasing overall efficiency.
  • Sturdy and Durable Construction: Designed for high-performance and heavy-duty use, this surface grinder is built with a solid, rugged construction that ensures long-lasting durability. It’s engineered to withstand the demands of continuous use while maintaining precise grinding performance.
  • Versatile Grinding Applications: This surface grinder can handle a wide range of materials, from metals to composites, making it highly versatile for diverse grinding tasks. Its ability to work with various materials increases its value in a range of industries.
  • User-Friendly Interface: Despite its advanced features, the USG1224-SY is equipped with an intuitive interface and programmable settings, making it easy for operators to adjust and control. The ease of use reduces training time and helps maximize the machine’s efficiency.
  • Cost-Effective in the Long Term: While the initial investment is substantial, the USG1224-SY’s precision, reliability, and long lifespan make it a highly cost-effective choice in the long run. Its consistent performance and low maintenance requirements contribute to overall savings for businesses.

Q: What is the U.S. Industrial Machinery 2-Axis Automatic Surface Grinder, 12” x 24” - USG1224-SY?
A: The U.S. Industrial Machinery USG1224-SY is a 2-axis automatic surface grinder designed for high-precision grinding of metal surfaces. With a 12” x 24” work surface, this machine offers increased capacity compared to smaller models, providing smooth, flat finishes for a variety of materials.

Q: What are the key features of the USG1224-SY?
A: The USG1224-SY features a 12” x 24” grinding area and a 2-axis automatic control system, offering precision and efficiency in metal surface grinding. It includes powerful motors, a durable construction, and an easy-to-use interface, ensuring consistent and high-quality results.

Q: What materials can the USG1224-SY handle?
A: The USG1224-SY is capable of grinding a wide range of metals, including steel, aluminum, and other alloys. It is commonly used for metal fabrication, tool sharpening, and achieving smooth, precise finishes on flat metal surfaces.

Q: What are the dimensions and weight of the USG1224-SY?
A: The USG1224-SY is designed to be robust yet compact for its size. For detailed specifications on dimensions and weight, please refer to the product manual or contact the manufacturer directly.

Q: Is the USG1224-SY easy to operate?
A: Yes, the USG1224-SY is designed for user-friendly operation. Its 2-axis automatic control system simplifies the grinding process, ensuring smooth performance even for operators with limited experience. It is built to provide precision with minimal effort.

Q: Does the USG1224-SY come with a warranty?
A: Yes, the USG1224-SY generally comes with a manufacturer warranty. For complete warranty details, please contact the manufacturer or an authorized distributor.

Q: Who is the USG1224-SY ideal for?
A: The USG1224-SY is ideal for use in medium to large-scale metalworking shops, tool and die shops, and industries that require precision surface grinding. Its large work surface and automatic features make it well-suited for applications that demand high-quality, consistent surface finishes.

  • Inspect Grinding Wheel: Check for wear, cracks, or any damage; replace the wheel when necessary to maintain a smooth and accurate grinding process.
  • Lubricate Moving Parts: Regularly grease the table, saddle, and cross-feed components to reduce friction, prevent rust, and maintain smooth movement.
  • Clean the Machine: Remove metal dust, grinding debris, and coolant residue from the machine after each use to avoid contamination and ensure smooth operation.
  • Hydraulic System Maintenance: Monitor hydraulic fluid levels and check hoses and seals for leaks; replace hydraulic oil per the manufacturer’s guidelines.
  • Electrical Component Check: Inspect all electrical systems, including switches and wiring, for damage or wear; verify the functionality of emergency stop buttons.
  • Check Bearings and Guides: Regularly inspect the bearings and guides for wear; replace or adjust as needed to ensure accurate and smooth table movements.
  • Tighten Fasteners: Ensure that all bolts, nuts, and fasteners are securely tightened to prevent vibrations and maintain machine stability.
  • Calibrate Alignment: Periodically check and adjust the machine’s alignment, including the grinding wheel and workpiece positioning, to ensure precision in grinding operations.
  • Follow Manufacturer’s Maintenance Schedule: Adhere to the recommended intervals for lubrication, part replacement, and machine checks for optimal performance.
