Our CNC control hydraulic press brakes offer users the ability to tackle any project with precision, speed, and volume.
These machines can handle the most demanding jobs with impeccable details. The capability to use a removable USB drive means that additional program storage is virtually limitless.
Features
-
6” LCD touchscreen to control the bend angle and back-gauge position
-
10 bends per program or cross-section
-
Up to 20 punch library and up to 50 die library
-
Auto bend sequence
-
Auto back-gauge retract
-
Spread length
-
Interference bend chart
-
Calculated bend allowance
-
Programmable ram dwell
Specifications
| Working Pressure |
125 Tons |
| Pressing Speed |
Dependent on Tool Load |
| Length of Working Table |
98.4” |
| Hydraulic Oil Capacity |
60 Gal. |
| Distance Between Housings |
80.7” |
| Motor Horsepower |
10 HP, 220 or 440 Volts, 3 ph. |
| Throat Depth |
12.5” |
| Net Weight |
16,534 lbs. |
| Stroke Adjustment of Ram |
1.96” |
| Length |
120” |
| Ram Travel |
5.5” |
| Width |
64” |
| Open Height |
15.9” |
| Height |
101” |
| Rapid Ram Travel Speed |
2.4”/sec. |
| Rapid Ram Retreat Speed |
2.0”/sec. |
| Backgauge Travel |
24” |
Package Includes
Videos
What Our Experts Think
The U.S. Industrial Machinery Hydraulic Press Brake (125 TON x 8’ - USHB125-8CNC) combines exceptional power with advanced technology, making it an excellent choice for precision metalworking. Here's why it's a standout option:
-
High Tonnage Capacity: Features a 125-ton capacity, ideal for handling heavy-duty bending and forming tasks across a range of industrial applications.
-
8-Foot Working Length: The generous 8-foot length accommodates larger workpieces, providing versatility for a wide variety of projects.
-
Graphic CNC Controls: Equipped with a user-friendly Graphic CNC system for precise and automated operation. This advanced control allows operators to program complex bends with accuracy and repeatability, increasing productivity and reducing errors.
-
Hydraulic Power: The hydraulic system ensures smooth, reliable performance with consistent pressure and precision in every operation.
-
Durable Construction: Engineered with a heavy-duty steel frame and robust components for long-lasting durability and reliability in demanding industrial environments.
-
Efficiency and Accuracy: The combination of CNC controls and hydraulic power delivers unparalleled efficiency and precision, reducing material waste and increasing overall output.
Q&A
Q: What is the U.S. Industrial Machinery Hydraulic Press Brake (USHB125-8CNC)?
A: It’s a hydraulic press brake with a 125-ton capacity and an 8-foot bending length, equipped with a Graphic CNC controller for enhanced precision and automated operations.
Q: How does it work?
A: The machine uses hydraulic power to bend metal sheets along a specified axis. The Graphic CNC controller allows operators to program and automate bending sequences, improving accuracy and efficiency.
Q: What makes it unique?
A: The addition of the Graphic CNC controller sets this press brake apart by providing programmable precision, repeatability, and ease of operation for complex bending tasks. Its 125-ton capacity and 8-foot length make it versatile for a wide range of materials.
Q: Who is it ideal for?
A: Ideal for medium to large-scale metalworking businesses and fabricators that require precise, repeatable bends and efficient workflow for high-volume or complex projects.
Q: Why choose this machine?
A: The U.S. Industrial Machinery Hydraulic Press Brake with Graphic CNC offers the perfect combination of power, precision, and automation, making it an excellent choice for improving productivity and maintaining high-quality results in metal fabrication.
Maintenance Tips
-
Daily Inspection: Examine for hydraulic leaks, misalignments, and unusual wear.
-
CNC System Care: Keep the CNC controller clean, and update firmware regularly.
-
Hydraulic Fluid: Check levels weekly; replace fluid and filters as specified by the manufacturer.
-
Lubrication: Apply grease to guides and moving parts as recommended.
-
Tooling Maintenance: Inspect and clean press brake dies; replace worn tooling to maintain precision.
-
Backgauge Calibration: Regularly calibrate the CNC-controlled backgauge for accurate positioning.
-
Electrical System: Check connections and monitor for overheating or loose wiring.
-
Alignment: Verify ram-to-bed alignment frequently to prevent uneven bending.
-
Environmental Control: Operate in a clean, temperature-controlled area to protect sensitive components.
-
Professional Servicing: Schedule annual servicing with a CNC technician for optimal performance.
