Grizzly Industrial 19" 5 HP Ultimate Bandsaw

Once you get your hands on this bandsaw, you'll agree it's the ultimate bandsaw!

The G0701 19' Ultimate Bandsaw is made for production work with its large cutting capacities, foot brake, resaw fence and motorized upper blade guide.

The 5 HP motor powers through wood at a maximum 19-1/2' cutting capacity and the 18-3/8' throat is big enough for most applications. No more cumbersome two-handed height positioning! Simply toggle the switch up or down for motorized blade guide adjustments.

The G0701 has an extra-wide 28' x 24' cast-iron table that can tilt from 5° left to 45° right. The cast-iron fence includes an extruded-aluminum resaw fence that attaches quickly and supports tall stock exceptionally well. The cast-iron table trunnions add additional weight for greater stability.

You'll also appreciate the computer balanced cast-iron wheels with rubber tires for the smoothest operation possible, blade tension gauge and rack and pinion table tilt adjustment. For a full range replacement and resaw blades for the G0701.

The G0701 19' Ultimate Bandsaw is covered by a 1-year warranty covering parts and factory defects. (Consumables such as blades are not included.) Support for this machine is US based and replacement parts may be available online for shipment from our warehouse in Springfield, MO.

Made in an ISO 9001 factory

CSA certified

Specifcations

• Motor: 5 HP, 230V, single-phase, 22A
• Guide post motor: Universal DC, 40W
• Cutting capacity/throat: 18-3/8'
• Maximum cutting height: 19-1/2'
• Table size: 28' x 24'
• Table tilt: 5° left, 45° right
• Floor to table height: 35-1/4'
• Blade size: 166–168' long
• Blade width range: 3/8 – 1-3/8'
• Blade speed: 4975 FPM
• Footprint: 31' x 23-1/2'
• Overall size: 86-1/2' H x 36-5/8' W x 33' D
• Approximate shipping weight: 810 lbs.

Features

• Rack-and-pinion, motorized upper blade guide height adjustment
• Blade tension gauge
• Height scale for upper blade guides
• Blade tracking window
• Dual ball-bearing blade guides
• Micro adjusting rack-and-pinion table tilting mechanism with support post
• Deluxe cast-iron fence with extruded aluminum resaw fence
• Included miter gauge
• Two 4' dust ports
• Quick-change blade release/tensioning
• Computer-balanced cast-iron wheels with rubber tires
• Hinged wheel covers with safety lock
• Foot brake
• Cast-iron table trunnion
• Magnetic switch with thermal overload protection
• Precision-ground cast-iron table
• Includes 1' bandsaw blade and miter gauge

What Our Experts Think

The Grizzly Industrial 19" 5 HP Ultimate Bandsaw is a powerful and precision-driven tool, designed for serious woodworkers. Here’s why it’s an exceptional choice:

• 5 HP Motor: Provides ample power for demanding cuts through thick hardwoods and large materials with ease.
• Large Cutting Capacity: With a 19" throat depth and 12" resaw capacity, it handles big projects and tall stock with precision.
• Precision and Stability: Features a heavy-duty, rigid frame and adjustable blade guides, ensuring accurate cuts and minimal vibration.
• Variable-Speed Control: Allows you to optimize performance for different materials and cutting tasks, enhancing versatility.
• Premium Build: Durable construction ensures long-lasting performance, even with continuous use in professional shops.

Q&A

Q: What is the Grizzly Industrial 19" 5 HP Ultimate Bandsaw designed for?
A: This high-performance bandsaw is designed for heavy-duty woodworking, offering precision cuts on large stock for professionals and serious woodworkers.

Q: How powerful is the motor?
A: It features a powerful 5 HP motor, delivering the strength needed for demanding cutting tasks.

Q: What is the cutting capacity?
A: The bandsaw offers a 19" throat depth and a 12" maximum cutting height, allowing for large workpieces and intricate cuts.

Q: What makes it the "Ultimate" Bandsaw?
A: The "Ultimate" design includes a robust construction, precision-engineered components, and superior features for top-tier performance in high-demand woodworking.

Q: Is the bandsaw easy to operate and adjust?
A: Yes, it features easy-to-use controls, adjustable blade guides, and a precision fence for accurate and convenient cutting.

Q: What are the key features of this bandsaw?
A: Key features include a durable cast-iron frame, heavy-duty motor, precision engineering, and an easy-to-adjust blade system.

Q: Why choose the Grizzly 19" 5 HP Ultimate Bandsaw?
A: It combines power, precision, and durability, making it an excellent choice for serious woodworkers and professionals seeking unmatched performance.

Maintenance Tips

• Blade Tension and Tracking: Regularly check blade tension and tracking for optimal cutting performance and smooth operation.
• Clean Blades and Wheels: Remove metal shavings and debris from the blade, wheels, and guides to avoid buildup and maintain precision cuts.
• Lubricate Moving Parts: Lubricate bearings, trunnions, and guides to minimize friction and ensure smooth movement.
• Motor Care: Inspect the motor for dust accumulation and clean as needed to ensure efficient performance.
• Dust Collection System: Keep the dust collection system clear to ensure proper airflow and prevent clogging.
• Belt and Pulley Inspection: Check belts and pulleys for signs of wear and replace them when necessary to maintain optimal speed control.
