Launch Tech USA Accessory Kit - LNCH-O2-1

Launch Tech USA Accessory Kit - LNCH-O2-1

BNC to 4 mm Test Leads: Test lead of a male BNC connector to (2) 4mm connectors. It is a kind of special line for assisting the Scope box to test various types of signals.4mm connectors are code din two colors. Black (earth wire)and red (positive pole which should be connected with the 6-way Breakout Leads).

6-way Breakout Leads: Moreover, it can also work with the 20:1 Attenuator. With these 6-way leads, you will be able to test most of the sensors and actuators on all makes and models or vehicle, including MAP, temperature, throttle position and airflow sensors, fuel pumps, primary ignition circuits and fuel injectors.

USB Cable: Connects the Scope box and diagnostic tool so that the sampled signal can be displayed on the diagnostic tool.

Battery Clamps Cable: To supply power to the Scope box through connection to vehicle's battery.

20:1Attenuator: It allows the Scope box to measure fuel injector and primary Ignition wave forms.

'Note: Please note this attenuator should be not used for any high voltage measurements other than fuel injectors and primary ignition.

Secondary Ignition Pick-up: This ignition pick-up is applied din the following Situations: Secondary-distributor ignition analysis, Secondary-simultaneous ignition analysis and Secondary-direct ignition analysis.

COP (Coil-on-Plug) Extension Cord: Coil-on-Plug extension cord (including earth cord) allows you to take accurate secondary ignition measurements on secondary-direct (Coil-on-Plug) ignition systems. It can be applied in the condition that there are no, or limited access to any spark plug leads.

Multimeter Probes

Crocodile Clips: Designed to connect the bare terminals or leads.

Back Probe Pins Suite: They are mainly used for piercing the insulation of wires to ' allow for automotive electrical measurements without i causing damage to the wires. Additionally they can be used as pin-tip probes while working with small circuit boards.

What Our Experts Think

• Comprehensive Tool Set: Includes essential accessories to enhance diagnostic testing and vehicle maintenance.
• Seamless Compatibility: Designed to work effortlessly with Launch X-431 diagnostic tools and devices.
• Durable Construction: Built with high-quality materials for long-lasting performance in workshop environments.
• Versatile Applications: Ideal for various diagnostic tasks — from sensor testing to power supply connections.
• User-Friendly Design: Organized layout for quick access, boosting efficiency during vehicle repairs.
• Portable & Compact: Easy to carry and store, making it perfect for both shop and mobile diagnostics.

Q&A

Q: What is the Launch Tech USA Accessory Kit (LNCH-O2-1)?
A: It’s a versatile accessory kit designed to enhance the functionality of Launch diagnostic tools, providing additional connectors and adapters for seamless vehicle diagnostics.

Q: What are the key features of the LNCH-O2-1?
A: Includes high-quality connectors, extension cables, and adapters, ensuring compatibility with a wide range of OBD-II vehicles.

Q: Why is the LNCH-O2-1 accessory kit important?
A: It expands the diagnostic capabilities of Launch tools, allowing technicians to connect to various vehicle models and access hard-to-reach OBD ports.

Q: Is the LNCH-O2-1 compatible with all Launch diagnostic tools?
A: Yes, it’s designed to work with most Launch Tech USA diagnostic devices.

Q: Where can I buy the LNCH-O2-1?
A: Available through authorized Launch Tech USA dealers and online marketplaces.

Maintenance Tips

• Component Check: Regularly inspect all accessories for wear, especially cables, connectors, and adapters.
• Clean Handling: Wipe accessories with a soft, dry cloth — avoid water or harsh chemicals.
• Organized Storage: Keep all items in the provided case to prevent loss or damage.
• Compatibility Review: Ensure all components match your diagnostic tools for seamless integration.
• Firmware Sync: Update any software-dependent accessories through your Launch Tech device.
