| Audio Output (GEOPHYSICAL SYSTEM) |
piezo buzzer Ø:12mm - H:9.8mm sound pressure level 85db at 12v/10cm frequency 4.5±0.5 kHz |
| Liquid Crystal Display (LCD) |
Touch screen full-colour 800 x 600 px (8 inch) - 165mm x 124 mm |
| Frequency |
2,91 kHz |
| Data processing speed |
11 MHz |
| Operating Temperature Range |
0 ° C to 60 ° C |
| Operating Humidity Range |
up to 95 % non-condensing |
| Storage Temperature Range |
- 20C° to 70C° |
| Storage Humidity Range |
up to 98 % Relative Humidity |
| Operating Time (54Wh Battery) |
(8 - 12) Hours |
| Waterproof Rating - Detector |
not waterproof (weatherproof only ) |
| Cables length |
20 m |
| Geophysical probe length |
810 mm |
| Long-range probe length |
340 mm |
| Bluetooth |
HC-06 2.4GHz Radio transceiver |
| weight total |
Systems Bag: 7500 g - Accessories Bag: 9200 g |
| Bag weight (empty ) |
Systems Bag (empty ): 3.5 kg - Accessories Bag (empty ): 3.5 kg |
| Bag dimensions |
Systems Bag (dimensions): 53cm x 40cm x 22.8 cm - Accessories Bag (dimensions): 53cm x 40cm x 22.8 cm |
| Battery Type |
Li-ion Rechargeable Battery - External Battery |
| Battery Output Voltage |
Li-ion 10.8 VDC |
| Battery Capacity |
Li-ion 54 Wh |
| Battery Run Time |
(8 - 12) Hours |
| Battery Operating Temperature |
0 ° C to 60 ° C |
| Battery Storage Temperature |
- 2C° to 70C° |
| Battery weight |
500 g |
| Charger Operating Temperature |
0 ° C to 50 ° C |
| Charger Storage Temperature |
- 30C° to 80C° |
| Charger Input Voltage |
90 → 250 VAC 50→60 Hz |
| Charger Output |
12.6 VDC / 1000 mA |
| Audio Output (LONG RANGE SYSTEM) |
piezo buzzer Ø:12mm - H:9.8mm sound pressure level 85db at 12v/10cm frequency 4.5±0.5 kHz |
| Liquid Crystal Display (LCD) |
full-colour 98mm x 57mm / 480x270 px |
| Length |
Device 170 mm - The device with long-range sensor 310mm |
| Frequency |
Max 500 KHz |
| Data processing speed |
8 MHz |
| Operating Temperature Range |
0 ° C to 70 ° C |
| Operating Humidity Range |
up to 95 % non-condensing |
| Storage Temperature Range |
- 20C° to 70C° |
| Storage Humidity Range |
up to 98 % Relative Humidity |
| Operating Time (27 Wh Battery) |
10 Hours |
| Waterproof Rating - Detector |
not waterproof (weatherproof only ) |
| Compass module |
GY-282 |
| The Device weight |
500 g |
| Battery Type |
Li-ion Rechargeable Battery - External Battery |
| Battery Output Voltage |
Li-ion 10.8 VDC |
| Battery Capacity |
Li-ion 27 Wh |
| Battery Run Time |
10 Hours |
| Battery Operating Temperature |
0 ° C to 60 ° C |
| Battery Storage Temperature |
- 2C° to 70C° |
| Battery weight |
350 g |
